MTX ThunderForm FESCP08FB10 Installation Manual

FESCP08FB10 Installation Guide
Ford Escape 2008 - 2012
(Unloaded/Loaded/Amplified)

STEP 1:

Clean out your vehicle, so you have a clear space to work.
NOTE!!
Note: Before drilling, make sure that you are not
going to be drilling into any gas lines, brake lines,
transmission lines, electrical wiring, transfer case
(4X4) vehicles) or anything else that might cause
a reduction in your weekly pay. Always wear eye
protection when drilling.

STEP 4:

Remove bottom plastic trim piece from rear left door
opening.

STEP 2:

Remove the woofer from the enclosure. Set enclosure in
place as shown. Using the hole in the back of the enclosure
as a guide, place a mark on the interior panel behind the
enclosure. This will be used to mount the enclosure. Drill a
hole in the interior panel where marked as shown.

STEP 3:

Remove plastic trim panel as shown.

STEP 5:

Remove side panel as shown.
