JMS08BD—GE Spacemaker
Dimensions (in inches)
Important: This range is designed to hang from the
countertop. It does not rest on the floor.
Countertop
If necessary, build up
sides to 1-1⁄2" thick to
provide screw anchor
surface and
countertop support
24-3/16
22-3/16
27-1/8
2
22-3/16"
Back of range
to front of
20"
closed door
Door
clearance
Specification Created 11/01
™ 27" Drop-In Electric Range
Trim section for
countertop with
post formed or
raised front
edge
Range side
support
30" MIN. to
bottom of
cabinet
over
range
18
28-1/2"
MIN.
28-7/16
29-9/16
27" Between
cabinets
Locate junction box
anywhere in shaded area
Note: Cabinets installed adjacent to drop-in ranges must have an
adhesion spec of at least 194°
For answers to your Monogram,
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center ® service, 800.626.2000.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
13/32
® GE Profile ™ or
Listed by
Underwriters
Laboratories
R
Countertop Cutout Top View
Inside back wall of cabinet
or rear wall
1-1/2" MIN.
Clearance
3/8" MIN. Flat
Adjoining
vertical
22-7/8"
21-3/4" cabinet
cabinet
Cutout
face to rear
or wall
of cutout
above
countertop
26-1/4" MAX.
Smooth cut
3" MIN.
(Both sides)
*If countertop edge is formed, this
dimension must extend to flat area
In replacement installation, use
JX27R optional backguard, if required
Optional Backguard
KW Rating
(Available at additional cost)
JX27RBK = Black
240V 10.1
JX27RWH = White
208V 7.6
Note: All 27" Drop-In Electric Ranges conform to U.L. requirements for
minimum spacing between range and side walls above countertop.
Installation Information: Before installing, consult installation
instructions, packed with product, for current dimensional data.
23-3/8" MIN.*
Flat
counter
