Installation Instructions
Wall Mounted Basketball Backstops
®
®
If you encounter any diffi culties installing or service your EZ-Fold
backstop, call
Copyright ©2010 Draper Inc.
Form EZFold-Wall_Inst10-R
Printed in U.S.A.
your dealer or Draper, Inc., Spiceland, Ind., (765) 987-7999 or fax (765) 987-7142.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Draper EZ FOLD
Summary of Contents for Draper EZ FOLD
- Page 1 Wall Mounted Basketball Backstops ® ® If you encounter any diffi culties installing or service your EZ-Fold backstop, call Copyright ©2010 Draper Inc. Form EZFold-Wall_Inst10-R Printed in U.S.A. your dealer or Draper, Inc., Spiceland, Ind., (765) 987-7999 or fax (765) 987-7142.
-
Page 2: Operation
® backstops by Draper, Inc., are designed to operate Draper, Inc. in any way and do not imply any re spon si bil i ty of Draper, for many years with a minimum of main te nance. However, you should Inc. - Page 3 If fraying is encountered, contact nuts progressively to make sure clamp is fully secured. your dealer or Draper, Inc. for re place ment. Caution: Wear gloves ➃ Pull the cable back through the hole to snug the clamp back tight to when searching for frays.
- Page 4 Page 4 of 18 EZ-Fold Basketball Backstops by Draper—Wall-Mounted Motor 1 HP Winch Terminal Block 110-120V/1/60 Instant reverse Green Green Ground White White Line 1, Neutral, white 110-120 Volt, 20 Amp Service Blue DOWN Blue/Black Black SWITCH (Hot) Blue Limit...
- Page 5 Page 5 of 18 EZ-Fold Basketball Backstops by Draper—Wall-Mounted Manual Winch 11 (Black/Hot) 12 (Down) 18 (Up) ➀ Find location according to project drawings. ➁ Four " diameter holes are provided for mounting the unit. The fastener type and size required will vary according to the type of mounting surface but must be adequate to safely sustain all loads imposed by the backstop system.
-
Page 6: Before Leaving The Jobsite
CAUTION and acrylic backboards Glue used to attach Draper backboard pad ding is extremely fl ammable. Keep away from heat and fl ame. Keep out of reach of children. Avoid prolonged ex po sure to fumes: Use in a well- ventilated area. - Page 7 EZ-Fold Basketball Backstops by Draper—Wall-Mounted Page 7 of 18 ® EZ-Fold Wall-Mounted Backstops by Draper Backstop Number: Backstop Model: Inspection/Maintenance List Periodically inspect your backstops and all related equip ment and attachments. Frequency of in spec tions depends on use of the equip- ment.
- Page 8 12" 15" " " 3" " " Typ. 0274 5' Wall Pad 0302 4' Wall Pad See next page for 7' wall pad. 5' and 6' wall pads also available. Contact Draper or see your project drawings. www.draperinc.com (765) 987-7999...
- Page 9 Page 9 of 18 EZ-Fold Basketball Backstops by Draper " Holes (6 Typ.) " Holes (12 Typ.) " 15" " 15" 15" " " Typ. " Typ. " " 2 " 7' Wall Pad (for use with DUW) Flat Inside...
- Page 10 Page 10 of 18 EZ-Fold Basketball Backstops by Draper ➁ Attach support mounts and Cable Sheaves to Wall Pads. Chain Mounting Bracket "-13 x 2 " Link " x " Carriage Bolts, Bronze Bushing Flat Washers, Lock Washers and Hex Nuts...
- Page 11 Page 11 of 18 EZ-Fold Basketball Backstops by Draper " O.D. Tubing " O.D. Tubing Brace Circle Clamp A0651 0651 (for attachment of horizontal Braces, including 0299 Circle Clamp (for attachment of vertical Braces). movable, locking Kick Brace on DGW).
- Page 12 Page 12 of 18 EZ-Fold Basketball Backstops by Draper Backboard (or ➅ Attach Chain Supports to Backstop (SW, SWD, DGW, Height Adjuster) and DUW). Hinge bracket part number varies per application Chain Support A0353 Eyebolt used to fold backstop Open/Close Chain Link Eye bolt used to fold backstop (DGW).
- Page 13 Page 13 of 18 EZ-Fold Basketball Backstops by Draper ➇ Assemble and attach Height Adjuster or Goal Brace NOTE: Use lift to raise and attach Bank Assembly. (SWD), Bank, and Goal. (See separate instructions for Height Adjuster assembly.) DUW Inner Leg NOTE: You cannot use a Goal Brace and Height Adjuster on the same backstop.
- Page 14 Page 14 of 18 EZ-Fold Basketball Backstops by Draper 0299 Circle Clamp " Chain 0035 Circle Clamp View 0274 5'-0" Wood Wall Pad A0313 7'-0" Wood Wall Pad A0303 Side View INSTALLATION NOTE: Attach and build legs and braces out from the wall.
- Page 15 Page 15 of 18 EZ-Fold Basketball Backstops by Draper A0303 0037 36" Wood Wall 0299 Circle 1 /4" Chain Clamp Front View 0035 Circle Clamp Oblique View 0035 Circle Clamp 0299 Circle Clamp INSTALLATION NOTE: Attach/build legs and Direct Mount Goal Brace from the wall out.
- Page 16 Page 16 of 18 EZ-Fold Basketball Backstops by Draper Please Note: To install telescoping brace, screw spring-loaded pin into hole provided on outer tube so that the head of the mechanism is toward the fl oor. slip inner tube into outer tube. Spring-loaded pin will pop into place.
-
Page 17: Linear Actuator
Page 17 of 18 EZ-Fold Basketball Backstops by Draper DGW-E Linear Actuator Wall Top View Side View www.draperinc.com (765) 987-7999... - Page 18 Page 18 of 18 EZ-Fold Basketball Backstops by Draper INSTALLATION NOTE: Attach A0339 and build legs from the wall A0339 out. Assemble Bank, Goal, and Height Adjuster, hoist and attach. 2" x 8" x 7'-0" Wood Wall Pad Aircraft Cable...
