Savio TR-12 User Manual

ENGLISH
Thank you for choosing our product!
If our product meets your expectations, share your opinion with
other people on the portal ceneo.pl, on social media or on the
website of the store where you made the purchase. If you want
to show off our device on Savio.net.pl FanPage on Facebook, we
will be very pleased.
If there is something that we could improve on our products, please
write to us at support@savio.net.pl
Thanks to your feedback, we will be able to better adapt the product
to your expectations.
Before starting the use of purchased device it is recommended
to read the whole manual.
1. Device installation
1.1 Insert Savio TR-12 transmitter into cigarette lighter socket.
1.2 Set the transmitter frequency between 87.6 and 107.9 MHz,
where no other signal is transmitted.
1.3 Turn on radio car and tune to the same frequency as on trans-
mitter.
1.4 Play music via Bluetooth or Micro SD card.
*If there is noise during playback, try setting a different frequency.
2. Product diagram:
1. USB 3A output (max) – Quick Charge
2. USB type C 18W output – Power Delivery
3. Rotating microphone
4. LED display
5. Bass Boost function on/off
6. Operation mode change button
7. Multifunction joystick
8. Micro SD card slot
9. Lighter socket plug
3. FM frequency settings on the transmitter
3.1 Press the
Press the key for about 2 seconds to enter the frequency key for about 2 seconds to enter the frequency
setting. When the LED screen starts flashing, you can proceed
to change the frequency on the transmitter.
3.2 Move to the right to increase frequency, move left to de-
crease it
4. Playing music
4.1 Playing music via Bluetooth
4.1.1 Turn on the Bluetooth mode on the transmitting device (e.g.
Smartphone), then turn on the device search and select
SAVIO TR-12 from the list. If transmitter have already been
paired with this device, they will be connected automatically.*
4.1.2 After proper connection with the device you will hear
a characteristic sound confirming correct pairing.
4.1.3 Device is ready to use.
* If the device asks for a passcode, enter „0000" or „1234"
4.2 Playing music via SD card
Inserting the Micro SD card into slot will automatically read and play it.
5. Functional buttons description
5.1 During playing music
• Single press to pause/resume playback
• Move right to select the next track
• Move left to select previous track
• Move up to increase volume level
• Move down to decrease volume level
5.2 During incoming calls (Hands-free function)
• Single press to answer an incoming call
• Press and hold to reject an incoming call
• Fast double press to call the last dialed number
5.3 During call (hands-free function)
• Single press to end the call
• Press and hold to turn on private mode
Car transmitter
User manual
5.4 Bass Boost button
model: TR-12
• Single press
• Press and hold
and the display in the device (the charger function will still be
available)
5.5 Button change work mode
• Press
on your phone
• Press twice quickly
Bluetooth and SD card
• Press and hold
6. Set contains:
• Transmitter SAVIO TR-12
• User manual
7. Technical specifications:
• Bluetooth version: 5.0
• Supported Bluetooth protocols: AVRCP, HFP, A2DP
• Frequency bands in which the radio equipment operates:
FM: 87.6 MHz – 107.9 MHz
Blutetooth: 2400 – 2483.5 MHz
• Power supply: 12V/24V
• Maximum radio-frequency power transmitted in the frequen-
cy band in which the radio equipment operates:
FM: 50nW e.r.p.
Bluetooth: 4dBm
• Output voltages for the PD port: 5V/3A, 9V/2A, 12V/1.5A
• Output voltages for the USB port: 5V/3A, 9V/2A,12V/1.5A
• Supports Micro SD cards: up to 64GB
• Supported file formats: MP3, WMA, APE, FLAC, WAV
8. Safety conditions:
• Use the product in accordance with its intended use, as im-
proper use may damage the product.
• Do not expose the device to moisture, heat or sunlight, do not
use the product in a dusty environment.
• The device should be cleaned only with a dry cloth.
• Independent repairs and modification result automatic loss of
the warranty.
• Hitting or dropping may damage the product.
POLSKI
Dziękujemy za zakup produktu marki Savio!
Jeśli nasz produkt spełnił Twoje oczekiwania, podziel się swoją
opinią z innymi osobami na portalu ceneo.pl, w mediach społec-
znościowych lub na stronie sklepu, w którym dokonałeś zakupu.
Będzie nam niezmiernie miło, jeśli zechcesz również pochwalić się
naszym urządzeniem na profilu Savio.net.pl na Facebooku.
Jeśli jest coś, co moglibyśmy poprawić w naszych produktach,
napisz nam o tym na adres: support@savio.net.pl
Dzięki Twojej opinii będziemy mogli jeszcze lepiej dopasować produkt
do Twoich oczekiwań.
Przed przystąpieniem do korzystania z zakupionego urządzenia zaleca
się przeczytanie całej instrukcji obsługi.
1. Instalacja urządzenia
1.1 Uruchom radio samochodowe i ustaw na nim częstotliwość
z zakresu 87.6 a 107.9 MHz, na której nie jest nadawany sygnał.
1.2 Włóż transmiter FM Savio TR-12 do gniazda zapalniczki samo-
chodowej.
1.3 Ustaw na transmiterze tę samą częstotliwość, jak wybrana
w radiu samochodowym.
1.4 Odtwarzaj muzykę poprzez Bluetooth lub z karty pamięci Micro SD.
*Jeśli podczas odtwarzania wystąpią zakłócenia, spróbuj ustawić
inną częstotliwość.
2. Schemat produktu:
to turn on / off Bass Boost function
to turn off / on the Bluetooth, FM functions
once to turn on / off the Google Assistant or Siri function
to change the playback source between
to turn on the LED iluminator
Instrukcja obsługi
Transmiter samochodowy
model: TR-12
