- Page 1 STORAGE BRIDGE The Modular Memory card Backup System User Guide Version Sep. 2014 NextoDI Co., Ltd. www.nextodi.com...
- Page 2 Thank you for purchasing the NEXTO STORAGE BRIDGE (NSB-25). All company and brand name mentioned in this article is for mere sorting and that each of its owned by its owner, NextoDI does not have any right for that. Please read this manual before using the product. Follow operating instructions For more inquiries, contact or consult our technical advisory service: carefully to avoid damage on the product, or personal injury.
-
Page 3: Table Of Contents
Table of Contents 1. CONTENTS OF THE NEXTO STORAGE BRIDGE DELETE THIS BACKUP ....................2. DEVICE DIAGRAM 14. MAKING A SECONDARY COPY (SYNC) ....................... 3. PRODUCT DESCRIPTION 15. EXPORT FOLDER ............................4. SYMBOLS USED IN THIS DOCUMENT 16. -
Page 4: Contents Of The Nexto Storage Bridge
1. Contents of the NEXTO STORAGE BRIDGE 1.1. Main Package 1.2. Sampler Pack (Optional) (1) Bridge Pellet x 2ea Hard drive (or SSD) protection rubber filler Mini screwdriver and screw set Rubber cover jacket (1) Main storage unit (2) Bridge Memory Module x 2ea (Optional) -
Page 5: Device Diagram
2. Device Diagram 3. Product Description NEXTO STORAGE BRIDGE (hereinafter NSB-25) provides the following functions. 3.1. Memory card backup and verify (16) NSB-25 contains a 2.5”SATA hard drive or SSD (Solid State Disk) and a Li-Poly rechargeable battery. NSB-25 provides an expandable backup solution, designed for the flexibility to create a backup from almost every memory card –... -
Page 6: Symbols Used In This Document
4. Symbols Used in This Document 3.7. Easy to use operating buttons The flash icon in a triangle indicates warning for personal Warning All functions can be operated using of 3 buttons – Power, Enter, Back and touch injury hazards such as electric shock. screen, the operative status is displayed on LCD. - Page 7 Warning Caution ● The case of the hard disk must not get damp or wet. Protect the ● The product must not get damp or wet. This product is not a toy. device from humidity and water, from sun, excessive heat (>113°F) It contains fragile and swallowable glass parts, small parts, and a or cold(<32ºF), dust and dirt.
-
Page 8: Insert & Remove Of Bridge Pellet
6. Installation of Hard Drive (or SSD) in Bridge Pellet 7. Insert & Remove of Bridge Pellet & Memory card Module NSB-25 includes 2 slots for 2 bridge pellets (sold separately) which can hold The bridge pellet and memory card module are interchangeable, it is easy to carry 2.5 inches SATA Hard drive (or SSD). -
Page 9: Charging The Rechargeable Battery
● The LED above the control key shows red when charging and firmware version will be shown on STORAGE Bridge ● When the battery is charged, the red LED turns off. the LCD. When you see the logo on the V1.00... -
Page 10: Key Operation
9.2. Key operation 9.4. Operation of touch screen Caution Power button ● Be careful to avoid contact an electrified matter with touch screen or a touch button. It may make touch screen do not work properly Enter button due to electrical stimulus such as static electricity. ●... -
Page 11: Xcopy Ready
Icons in main area 9.6. XCopy Ready Log file When only one Bridge Pellet or one USB external drive is equipped, NSB-25 shows the main screen of “XCopy Ready” and performs single copy. Set up Equipped bridge pellet 14:30:29 10-JAN-2013 XCopy Ready Not Equipped bridge pellet HDD 0... -
Page 12: Formatting The Hard Drive (Or Ssd)
10. Formatting the Hard Drive (or SSD) When 2ea of Bridge Pellet are equipped, the screen shows as below. The hard drive installed in bridge pellet requires to be self formatted 14:30:29 10-JAN-2013 MCopy Ready Caution HDD 0 780 GB ●... - Page 13 Changing of the drive name 14:30:29 10-JAN-2013 HDD 1 HDD 1 Secondly, All data in drive will be 14 Backups ( 200GB / 980GB ) 14 Backups ( 200GB / 980GB ) DELETED 14:30:29 10-JAN-2013 Browse Folders Browse Folders Backup Name Backup Name Size Size...
-
Page 14: Using An External Usb Hard Drive
11. Using an External USB Hard Drive 12. Data Backup (Copy) and Verify NSB-25 can be connected to USB external drive through USB 3.0 interface so that The built-in slots of CF & SD and optional modules support various memory cards it is possible to use the function of copy and SYNC in external drive. -
Page 15: Status
12.3. Status Make a new folder on the hard drive (or SSD) and copy all Fast Copy the memory card data into the folder. 14:30:29 10-JAN-2013 The execute function (Copy or verify) New SxS Same as [Fast Copy] but after copying, the data on the Total number of files in the memory Copy &... -
Page 16: Display Previous Backup Status
13. Show Video & Photo 12.5. Display previous back up status You can check the contents stored in bridge pellet or external drive or memory card with the function of Browse Folders. When the error occurs during the backup, the error message is displayed and NSB-25 is automatically turned off. -
Page 17: Show Photo
14. Making a Secondary Copy (SYNC) You can easily copy all files from an internal hard drive module to another drive Press the clip to play. when two or more hard drives are connected. 14:30:29 10-JAN-2013 00000000.MXF (1) Total play time 00:01:23 00:06:23 (2) Progress of play... -
Page 18: Export Folder
15. Export Folder When it is connected to more than one bridge pellet or USB external drive, Reference 00:06:23 the selected folder in selected drive can be copied from one drive to another. ● If an error occurs during the “Sync” function, the NSB-25 will automatically shut down and display an error message at the next power up. -
Page 19: Using The Nsb-25 As A Hard Drive (Or Ssd)
16. Using the NSB-25 as a Hard Drive (or SSD) 14:30:29 10-JAN-2013 The NSB-25 and Bridge Pellet can be connected to your computer for use as an Executing of export. 00:06:23 New SxS external hard drive. Syncing Reference HDD 0 780 GB 3 / 4 Folders ●... -
Page 20: Bridge Pellet Connection To Compuer
16.2. Bridge Pellet connection to computer ● When connecting to computer normally, XDROOT 00:06:23 the bridge pellet indicates the designated name File Edit View Facorites T (1) Turn your computer on. Wait until the operating system has completely booted. 검색 검... -
Page 21: Track Of Usage With Log File
17. Track of Usage with Log File 18. Hard Drive (or SSD) Management NSB-25 generates a LOG file (CRC-protected) to keep track of usage by the user and This is the function of HDD management of bridge pellet and USB external drive. then save it on each drive (bridge pellet &... - Page 22 (1) SMART Test Caution 14:30:29 10-JAN-2013 The quick test takes several minutes to HDD 1 HDD 1 14 Backups ( 200GB / 980GB ) 14 Backups ( 200GB / 980GB ) ● The NSB-25 buzzer (repeating every 3 seconds) indicates the test the internal hard drive.
-
Page 23: Delete Tmp Folders
18.3. Delete TMP Folders 14:30:29 10-JAN-2013 When error found during full test, Full Test further use of the selected drive may HDD 1 128m52s This is for cleanup of TMP folders generated when backup is failed. 0 Bad Clusters found. result in the loss of backup data. -
Page 24: Setup Functions
19. Setup functions 14:30:29 10-JAN-2013 Reference Touch “Setup” icon in the bottom right MCopy Ready of the main screen of XCopy/MCopy ● Users can use “NxCrcChecker” program provided by NextoDI to check if the Ready. HDD 0 video file is changed from its original copy. 780 GB HDD 1 780 GB... -
Page 25: Date & Time
19.6. Date & Time 14:30:29 10-JAN-2013 The LCD screen indicates that the NSB-25 Setup Setup firmware is being updated. Do not turn 14:30:29 10-JAN-2013 Auto Power Off Auto Power Off 90 sec 90 sec HDD 1 HDD 1 You can set date (D/M/Y) & time (H/M/S). CRC Check during Copy CRC Check during Copy the power off during the firmware... -
Page 26: Troubleshooting Tips
20. Troubleshooting Tips 21. Battery Disposal 20.1. IF THE POWER OF THE NSB-25 CANNOT BE TURNED OFF : Batteries/rechargeable batteries containing harmful substances are marked with the following symbols: Cd=cadmium, Hg=mercury, Pb=lead. You can return The Power Button can be used as a reset key. In the event of a hardware or batteries/ rechargeable batteries to any authorized disposal station in your area or software malfunction, press the power button for at least 7 seconds. -
Page 27: Technical Specification
22. Technical Specification Model Name NEXTO STORAGE Bridge Model Name Bridge Pellet Model Number NSB-25 Model Number NSB-BP1 5” Color TFT LCD: 800*480, 24bit color 2.5 inches, 9.5 mm height SATA(1/2/3) hard drive or Internal Drive Solid State Drive Built in slot: CF / SD (SDHC/SDXC with UHS-1 support) Computer connection USB 3.0 device (5Gbps)
