CAUTION
This product was designed to be installed on wood stud walls and solid concrete walls.
Before installing make sure the supporting surface will support the combined load of the
equipment and hardware. Never exceed the Maximum Load Capacity. This product is
intended for indoor use only. Use of this product outdoors could lead to product failure or
personal injury.
INSTALLATION GUIDE: BC79138
•
HAV Advanced Installer Mount
•
Single stud installation
•
322mm articulated dual arm TV MOUNT
•
TV size range 10"～24" [25-60cm]
•
Maximum weight capacity 15kg/33.3lbs
•
Adjustable angle:: -5～15
•
VESA 75 x 75 , VESA 100 x 100
•
Easy mount system
•
Cable manager
•
Colour silver
Thank you for choosing our product
1
Advertisement
Related Manuals for Hills BC79138
Summary of Contents for Hills BC79138
- Page 1 INSTALLATION GUIDE: BC79138 • HAV Advanced Installer Mount • Single stud installation • 322mm articulated dual arm TV MOUNT • TV size range 10"～24" [25-60cm] • Maximum weight capacity 15kg/33.3lbs • Adjustable angle:: -5～15 • VESA 75 x 75 , VESA 100 x 100 •...
- Page 3 Part 1a- Wood Stud Mounting Use wall plate as a template, make sure it is level, and mark four mounting holes on the wood studs. Drill four 3/16” (4.5mm) dia.holes 2”(50mm) deep. Level wall plate and attach to wall with four long bolts(D) and four washers (H).
- Page 5 Lift the screen and hook spacers(F) on to the wall plate. Fasten the bottom of the screen to wall plate using two selected bolts and two spacers(G). Tighten bolts firmly. Do not overtighten. NOTE: Allen wrench may be needed to adjust the swivel of the mount.
- Page 6 Warning This product contains small items that could be a choking hazard if swallowed. Keep these items away from young children! NOTE: Always use an assistant or mechanical lifting equipment to safely lift and position heavy equipment. The manufacturer or supplier takes no responsibility for damage or injury due to incorrect procedure or installation.
