CAUTION
This product was designed to be installed on wood stud walls and solid concrete walls.
Before installing make sure the supporting surface will support the combined load of the
equipment and hardware. Never exceed the Maximum Load Capacity. This product is
intended for indoor use only. Use of this product outdoors could lead to product failure or
personal injury.
INSTALLATION GUIDE: BC78203
HAV Advanced Installer Mount
•
ULTRA SLIM 14mm TV FIXED MOUNT
•
TV size range 42"～65"[105-162.5cm]
•
Maximum weight capacity 45kg/99lbs kg /105lbs
•
Tilts up for easy cable access
•
NON VESA & VESA 800 X 500
•
Dual safety pins
•
Colour silver
•
Thank you for choosing our product
1
Advertisement
Table of Contents
Related Manuals for Hills Clever HAV BC78203
Summary of Contents for Hills Clever HAV BC78203
- Page 1 INSTALLATION GUIDE: BC78203 HAV Advanced Installer Mount • ULTRA SLIM 14mm TV FIXED MOUNT • TV size range 42"～65"[105-162.5cm] • Maximum weight capacity 45kg/99lbs kg /105lbs • Tilts up for easy cable access • NON VESA & VESA 800 X 500 •...
- Page 2 Hardware List: Part 1a- Wood Stud Mounting Use wall plate(1) as a template, make sure it is level, and mark three mounting holes along the center lines of the wood studs. Drill three 3/16” (5mm)dia.holes 2”(50mm) deep. Level wall plate(1) and attach to wall with three long bolts(F) and three washers(H).
- Page 3 Part 1b- Concrete Wall Mounting Level wall plate(1) and use it as a template to mark three holes. Drill three 3/8”(10mm) dia. holes 2” (50mm) deep. Insert three anchors(G) into holes and secure wall plate with three long bolts(F) and three washers(H).Tighten screws firmly.
- Page 4 Part 2a- Attaching Brackets To Screen With Flat Back Center brackets vertically on back of screen. Select the small(A or B), medium(C or D) or large(E) screws. Attach brackets to screen using four selected screws and four square washers(F) at the top and bottom of each bracket.
- Page 5 Part 4- Insert the thrusting pin Use thrusting pins(3) to prevent the TV from being removed or accidentally knocked off of the wall plate. Since the mount plate is thin, you could not put your hand behind the screen to insert the thrusting pin(3), use the ribbon(4) for a help, when the pin is settled, pull back the connected underlay(5).
- Page 6 Warning This product contains small items that could be a choking hazard if swallowed. Keep these items away from young children! NOTE: Always use an assistant or mechanical lifting equipment to safely lift and position heavy equipment. The manufacturer or supplier takes no responsibility for damage or injury due to incorrect procedure or installation.
