24" LCD Monitor
Dell SE2417HGX
Service
Service
Service
Simplified
1

Advertisement

Table of Contents
loading

Related Manuals for Dell SE2417HGX

Summary of Contents for Dell SE2417HGX

  • Page 1 24" LCD Monitor Dell SE2417HGX Service Service Service Simplified...

  • Page 2: Important Safety Notice

    Accordingly, a servicer who uses a service procedure or tool which is not recommended by DELL must first satisfy himself thoroughly that neither his safety nor the safe operation of the equipment will be jeopardized by the service method selected.
  • Page 3 1.Exploded view diagram with list of items...
  • Page 4 MAIN BOARD 0D1G1030 6120 SCREW D3 6 0M1G1740 8120 SCREW M4 8 Q15G246550100000GH MAINFRAME Q33G0694AEF01L0100 0Q1G 130 6120 SCREW Q3 6 Q34G82020VH0DL0130 REAR_COVER Q15G0233 2 MAINFRAME Q23G315570000500CN LOGO DELL 27 0M1G3030 4 47 CR3 SCREW P3 4 Q37G055501100000ML stand-base ass'y...
  • Page 5 2.Wiring connectivity diagram Connector Ass’y PN: Connector Ass’y PN: 395G801406DJ61 395G179W30P0420000 This Connector welding Connector Ass’y PN: 395GH20011LM0050HF in Key Board...

  • Page 6: Mechanical Instruction

    3. Mechanical Instruction Tools Required List the type and size of the tools that would typically can be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description: - Phillip-head Screwdriver -Hexagonal head Screwdriver - Penknife...
  • Page 7 3.1 Disassembly Procedures: Step Figure Remark Turn off power, S1. Before Unplug external disassemble cables from product To remove the stand: 1. Wedge your fingers Press and hold the stand release button. 2. Lift the stand up and away from the monitor. S2.Remove the STAND-BASE Note:...

  • Page 8: Rear Cover

    Use a Philips-head screwdriver to remove 2 screws for unlocking mechanisms. (No.1~2 screw size=M3x4; Torque=4±1kgf.cm) S3.Remove the REAR COVER Use Penknife to separate the bezel and rear cove follow the arrows in sequence, then you can take out rear cover. S4.Disconnect the connectors,and tear off the tapes...
  • Page 9 Use a hex screwdriver to remove 2 screws for S5.Unscrew the unlocking mainboard. hex screws (No.1~2 is Hex-screw, Torque= 4.5±0.5kgf.cm) Use a Philips-head screwdriver to remove 5 screws for unlocking S6.Unscrew the mainboard. screws to remove (No.1~4 screw the Main board size=M4x8;Torque= and Power board 6±1kgf.cm;...

  • Page 10: The Main Frame

    Use a Philips-head screwdriver to remove 5 S9. Remove the screws for unlocking screw mainboard. (No.1 screw size=Q3x6; Torque=4±1kgf.cm) The MAIN FRAME The PANEL The BEZEL...
  • Page 11 3.2 Assembly Procedures: Step Figure Remark Use a Philips-head screwdriver to tighten S1.Assembly the 1screws for locking main frame main fraim (No.1 screw size= Q3x6 Torque=4±1kgf.cm)   Use a Philips-head screwdriver to tighten 4 screws for locking Key S2.Assembly the board.
  • Page 12 Use a Philips-head screwdriver to tighten 5 screws for locking mainboard and power board (No.1~4 screw size=M4x8; Torque= 6±1kgf.cm; No.5 screw size=D3x6; Torque= 6±1kgf.cm) S4. Assembly the MAIN FRAME and Pasted the Assembly the TAPEs MAIN FRAME and connect the panel FFC cable S5.Connect the cables...
  • Page 13 Use a hex screwdriver to tighten 2 screws for S6.Tighten he locking mainboard. VGA port (No.1~2 is Hex-screw, Torque= 4.5±0.5kgf.cm) Assembly the Rear cover. Use a Philips-head screwdriver to tighten 2 S7.Assembly the screws for locking REAR COVER mechanisms. (No.1~2 screw size=M3x4;...

  • Page 14: Troubleshooting Instructions

    Trouble shooting instructions...
