MICRO LAVALIER MICROPHONE
3 mm (0.12 in) subminiature microphone
Xvive LV2 is a high-performance 3 mm (0.12 in) subminiature lavalier microphone. It
o ers a high level of speech intelligibility, and is easily hidden in costumes/hair,
buttonholes etc.—even glued on performers' faces—in lm, theater, and broadcast.
• Superior audio clarity
• Natural response across the frequency range
• 3 mm (0.12 in) subminiature lavalier microphone
• Small and easily concealed
• Matte black, sleek, low-pro le design
• Microphone capsule with omni-directional pickup pattern
• The plug locks and is compatible with standard TRS interface
LV2 LAVALIER MICROPHONE
Polar pattern
Sensitivity
Equivalent noise level
Impedance
Frequency response
Battery voltage range
Battery drain
Maximum input level
Microphone Connector
Mono 3.5mm TRS output. Ensure the
connected device provides a regulated +
0.8V to 5V voltage to the "+" conductor.
FEATURES
Omni-directional
-40dB ±3dB
28 dB SPL
4.5 k
50 Hz – 20 kHz
0.8-5 VDC
17 µA
117.5 dB SPL
TRS Wiring Diagram
"+" Audio output
and bias voltage
Ground
