R3/R4 Motherboard (with UEFI BIOS)
User Manual
01750356875A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DIEBOLD NIXDORF R3

  • Page 1 R3/R4 Motherboard (with UEFI BIOS) User Manual 01750356875A...
  • Page 2: Table Of Contents

    Table of Contents 1 Symbols ............................1-1 2 Important notes .......................... 2-1 3 Warranty ............................. 3-1 4 ESD (Electrostatic Sensitive Devices) ..................4-1 5 Specifications of R3/R4 Motherboard ..................5-1 6 Motherboard Variants ........................ 6-1 R3/R4 Motherboard......................6-1 6.1.1 Front view......................6-1 6.1.2...
  • Page 3 14.2 HDD Security Configuration ....................14-4 15 Boot ............................. 15-1 15.1 UEFI Hard Disk Drive BBS Priorities..................15-4 15.2 UEFI NETWORK Drive BBS Priorities ................15-5 16 Exit .............................. 16-1 17 Certifications of the Manufacturer ................... 17-1 18 Recycling ............................ 18-1 Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 4: Symbols

    This warning note describes a hazard with a low degree of risk, which, if not avoided, will result in death or grave bodily injury. NOTE This note provides application tips and information that help prevent errors and material damage. Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 5: Important Notes

    Before you install or remove any component, always remove the AC power by unplugging the power cord from the power outlet. Failure to do so may cause severe damage to the motherboard, peripherals, or components. Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 6: Warranty

    3 Warranty Generally Diebold Nixdorf guarantees a warranty engagement for 12 months beginning with the date of delivery. This warranty engagement covers all damages which occur despite a normal use of the prod- uct. Damages because of improper or insufficient maintenance, improper use of the product or unauthorized modifications of the product, inadequate location or surroundings will not be covered by the warranty.
  • Page 7: Esd (Electrostatic Sensitive Devices)

    The equipment and tools you use must be free of static charges. Always hold boards with ESDs by their edges. Do not touch the components. Never touch pins or conductors on boards fitted with ESDs. Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 8: Specifications Of R3/R4 Motherboard

    5 Specifications of R3/R4 Motherboard Model Name Processor Support 9th/8th Generation Intel® Core™ 9th/8th Generation Intel® Core™ i5 processors for LGA 1151 i3 or Celeron® processors for socket LGA 1151 socket Chipset Q370 H310 Memory socket DDR4 1866/2133 MT/s SODIMM up to 32GB...
  • Page 9 Specifications of R3/R4 Motherboard 1x USB Type-C, PD 2.0, DP 1.2, DFP (5V/12V) TPM 2.0 Support TPM Daughter board interface Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 10: Motherboard Variants

    6 Motherboard Variants R3/R4 Motherboard 6.1.1 6.1.1 Front view SODIMM socket WLAN module M.2 2280 socket (SSD) RTC battery Docking board interface Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 11: Back View

    Motherboard Variants 6.1.2 6.1.2 Back view Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 12 Motherboard Variants IO Board Power Board TPM option CMOS clear Heat sink Connection for TSE/MF module Heat Sink Fan M.2 2280 socket (SSD) Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 13: Block Diagram

    7 Block diagram R3/R4 Motherboard Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 14: Central Processing Unit

    This Motherboard supports 9th/8th Generation Intel® Core™ i5/i3 or Celeron® processors for LGA 1151 socket. System Memory This Motherboard Supports 1 piece Double Data Rate 4 (DDR4) Small Outline Dual Inline Memory Mod- ule (SO-DIMM). The figure below illustrates the location of the DDR4 SO-DIMM socket.. Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 15: Jumpers

    CPU Parameter Recall (C.P.R) feature. Shut down and reboot the system so the BIOS can automatically reset parameter settings to default values. This jumper will just load BIOS defaults, and will not clear BIOS password. Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 16: Connectors

    USB 3.0 (Type C with DP and PD 5/24V) Power source/sink function USB6 USB 3.0 (Type A) COM3 RJ50 powered COM port (5V/12V) COM2 RJ50 powered COM port (5V/12V) COM1 RJ50 powered COM port (5V/12V) Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 17 Due to the design of the Intel® 300 series chipset, all USB devices connected to the USB 2.0 and USB 3.1 Gen 2 ports are controlled by the xHCI controller. Some legacy USB de- vices must update their firmware for better compatibility. Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 18: Internal Connectors

    This connector supports a Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 19 Central Processing Unit Connection for TSE/MF module Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 20 Motherboard while the other is installed on the top side of Motherboard (under Heat Sink Fan) NOTE The M.2 SSD module is purchased separately. This socket supports M-Key and 2260/2280 SATA/PCIe mode storage devices. Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 21 Central Processing Unit M.2 Socket (E-Key WIFI Module) NOTE The M.2 WIFI module is purchased separately. This socket supports E-Key WIFI Modules Intel® Wireless-AC 9462 (Celeron/i3/i5 variant motherboards) and Intel® Wireless-AC 9560 (i5 Variant motherboard) Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 22: Raid

    This motherboard provides RAID functionality for the SATA interface. Raid level 0 (striping), 1 (mirroring) and 5 (striping with distributed parity) are supported. For RAID 5 three HDD/SSD devices are needed. To enable the RAID functionality please see the corresponding chapter in the BIOS setup description. Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 23: Bios Setup Program

    Once the crash happens, all you need to do is reboot. Your system will automatically activate BIOS self- recovery. EZ Flash will read the BIOS (.cap) file stored in the hidden area of your HDD, and start recov- ering the BIOS. Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 24: Bios Menu Screen

    Exit For selecting the exit options and loading default settings. To select an item on the menu bar, press the right or left arrow key on the keyboard until the desired item is highlighted. Copyright © 2021, Diebold Nixdorf 01750356875A...
  • Page 25: Information

    A UUID is an identifier standard used in software construction, standardized by the Open Software Foundation. The intent of the UUIDs is to enable distributed systems to uniquely identify information without significant central coordination. Copyright © 2021, Diebold Nixdorf 10-1 01750356875A...
  • Page 26: Main

    To set the date, use tab switch between date elements. Default Ranges: Year: 2005-2009 Months: 1-12 Days: dependent on month Press numeric keys to enter. System Time: To set the time, use tab switch between time elements. Press numeric keys to enter. Copyright © 2021, Diebold Nixdorf 11-1 01750356875A...
  • Page 27: Advanced

    SATA And RST Configuration: SATA Device Options Settings NVMe Configuration: NVMe Device Options Settings USB Configuration: USB Configuration Parameters Onboard Devices Configuration: Onboard Devices Options Settings Super IO Configuration: System Super IO Chip Parameters Copyright © 2021, Diebold Nixdorf 12-1 01750356875A...
  • Page 28 DN MCU Configuration IO HUB Configuration: IO HUB Configuration Watchdog Timer: Watchdog Timer Miscellaneous: Miscellaneous Network Stack Configuration: Network Stack Settings. Intel(R) Ethernet Connection (7) I219-V – Configure Gigabit Ethernet device parameters D8:50:DA:22:33:20 Copyright © 2021, Diebold Nixdorf 12-2 01750356875A...
  • Page 29: Video Configuration

    Advanced 12.1 12.1 Video Configuration Boot Display Priority: Boot Display Priority Copyright © 2021, Diebold Nixdorf 12-3 01750356875A...
  • Page 30: Apm Configuration

    Advanced 12.2 12.2 APM Configuration 12.3 12.3 EZ-Flash Enter Ez-Flash mode Enter Ez-Flash mode Copyright © 2021, Diebold Nixdorf 12-4 01750356875A...
  • Page 31: Cpu Configuration

    Some of the parameters in the CPU Configuration submenu are only available under certain conditions. Intel (VMX) Virtualization Tech- When enabled, a VMM can utilize the additional hardware capabili- nology: ties provided by Vanderpool Technology. VT-d: VT-d capability Copyright © 2021, Diebold Nixdorf 12-5 01750356875A...
  • Page 32: Trusted Computing

    Secure Device Support: Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Copyright © 2021, Diebold Nixdorf 12-6 01750356875A...
  • Page 33: Sata & Rst Configuration

    Advanced 12.6 12.6 SATA & RST Configuration SATA Controller(s): Enable/Disable SATA Device. SATA Mode Selection: Determines how SATA controller(s) operate. This PCH SKU doesn’t support RST feature. Copyright © 2021, Diebold Nixdorf 12-7 01750356875A...
  • Page 34: Software Feature Mask Configuration

    If enabled, indicates that the HDD password unlock in the OS is enabled. LED Locate: If enabled, indicates that the LED/SGPIO hardware is attached and ping to locate feature is enabled on the OS. Copyright © 2021, Diebold Nixdorf 12-8 01750356875A...
  • Page 35: Nvme Configuration

    Advanced 12.7 12.7 NVMe Configuration Copyright © 2021, Diebold Nixdorf 12-9 01750356875A...
  • Page 36: Usb Configuration

    Advanced 12.8 12.8 USB Configuration USB Enumeration Delay: USB Enumeration Delay, unit: 100m seconds USB Single Port Control: USB Single Port Control Copyright © 2021, Diebold Nixdorf 12-10 01750356875A...
  • Page 37: Usb Single Port Control

    USB Type C DRP USB HS #2: USB Type C DFP USB HS #7: USB 2.0 Type A (Left) USB HS #8: USB 2.0 Type A (Middle) USB HS #9: USB 2.0 Type A (Right) Copyright © 2021, Diebold Nixdorf 12-11 01750356875A...
  • Page 38: Onboard Devices Configuration

    COM port 1 power delivery COM port 2 power delivery: COM port 2 power delivery COM port 3 power delivery: COM port 3 power delivery Onboard Cash Drawer: Onboard Cash Drawer LAN 1219: Enable/Disable onboard NIC. Copyright © 2021, Diebold Nixdorf 12-12 01750356875A...
  • Page 39: Super Io Configuration

    Serial Port 1 Configuration: Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration: Set Parameters of Serial Port 2 (COMB). Serial Port 3 Configuration: Set Parameters of Serial Port 3 (COMD). Copyright © 2021, Diebold Nixdorf 12-13 01750356875A...
  • Page 40 Advanced 12.10.1 12.10.1Serial Port 1 Configuration Serial Port: Enable or Disable Serial Port (COM). Change Settings: Select an optimal settings for Super IO Device. Copyright © 2021, Diebold Nixdorf 12-14 01750356875A...
  • Page 41 Advanced 12.10.2 12.10.2Serial Port 2 Configuration Serial Port: Enable or Disable Serial Port (COM). Change Settings: Select an optimal settings for Super IO Device. Copyright © 2021, Diebold Nixdorf 12-15 01750356875A...
  • Page 42 Advanced 12.10.3 12.10.3Serial Port 3 Configuration Serial Port 3: Enable or Disable Serial Port (COM). Change Settings: Select an optimal settings for Super IO Device. Copyright © 2021, Diebold Nixdorf 12-16 01750356875A...
  • Page 43: Serial Console Redirection

    Advanced 12.11 12.11 Serial Console Redirection Console Redirection 0: Console Redirection Enable or Disable. Console Redirection 1: Console Redirection Enable or Disable. Console Redirection 2: Console Redirection Enable or Disable. Copyright © 2021, Diebold Nixdorf 12-17 01750356875A...
  • Page 44: Smart Settings

    Advanced 12.12 12.12 SMART Settings SMART Self Test: Run SMART Self Test on all HDDs during POST. Copyright © 2021, Diebold Nixdorf 12-18 01750356875A...
  • Page 45: Dn Mcu Configuration

    Advanced 12.13 12.13 DN MCU Configuration Copyright © 2021, Diebold Nixdorf 12-19 01750356875A...
  • Page 46 This is the duration in unit of 100msec. For example, a value of 1 equals 100msec and a value of 35 equals 3.5sec. Copyright © 2021, Diebold Nixdorf 12-20 01750356875A...
  • Page 47: Io Hub Configuration

    Advanced 12.14 12.14 IO HUB Configuration COM5: COM5 COM6: COM6 COM7: COM7 USB1: USB1 USB2: USB2 PUSB12: PUSB12 PUSB24: PUSB24 Cash Drawer: Cash Drawer Copyright © 2021, Diebold Nixdorf 12-21 01750356875A...
  • Page 48: Watchdog Timer

    Advanced 12.15 12.15 Watchdog Timer Watchdog Support: Enable/Disable Watchdog Support Copyright © 2021, Diebold Nixdorf 12-22 01750356875A...
  • Page 49: Miscellaneous

    Advanced 12.16 12.16 Miscellaneous Start HDD Diagnosis: HDD Diagnosis tool Start Quick Memory Diagnosis: Quick Memory Diagnosis Tool Start CPU Stress Diagnosis: CPU Stress Diagnosis Copyright © 2021, Diebold Nixdorf 12-23 01750356875A...
  • Page 50: Network Stack Configuration

    Enable/Disable Ipv4 PXE boot support. If disabled, IPv4 PXE boot support will not be available. Ipv6 PXE Support: Enable/Disable Ipv6 PXE boot support. If disabled, IPv6 PXE boot support will not be available. Copyright © 2021, Diebold Nixdorf 12-24 01750356875A...
  • Page 51: Intel(R) Ethernet Connection (7) I219-V - D8:50::Da:22:33:20

    12.18 Intel(R) Ethernet Connection (7) I219-V - D8:50::DA:22:33:20 NIC Configuration: Click to configure the network device port. Blink LEDs: Identify the physical network port by blinking the associated LED. Link Status: Link Status. Copyright © 2021, Diebold Nixdorf 12-25 01750356875A...
  • Page 52: Nic Configuration

    Advanced 12.18.1 12.18.1NIC Configuration Link Speed: Specifies the port speed used for the selected boot protocol. Wake On LAN: Enables the server to be powered on using an in-band magic packet. Copyright © 2021, Diebold Nixdorf 12-26 01750356875A...
  • Page 53: Hardware Monitor

    13 Hardware Monitor Smart Fan Mode: Smart Fan Mode Select. Copyright © 2021, Diebold Nixdorf 13-1 01750356875A...
  • Page 54: Security

    14 Security Administrator Password: Set Administrator Password. Secure Boot: Secure Boot configuration. HDD Security Configuration: HDD Security Configuration. Copyright © 2021, Diebold Nixdorf 14-1 01750356875A...
  • Page 55: Secure Boot

    Secure Boot mode options: Standard or Custom. In Custom mode, Secure Boot Policy variables can be configured by a physically present user without full authentication. Key Management: Enables expert users to modify Secure Boot Policy variables without full authentication. Copyright © 2021, Diebold Nixdorf 14-2 01750356875A...
  • Page 56: Key Management

    1. Public Key Certificate: Authorized Signatures: a) EFI_SIGNATURE_LIST Forbidden Signatures: b) EFI_CERT_X509 (DER) Authorized Timestamps: c) EFI_CERT_RSA2048 (bin) OsRecovery Signatures: d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/C0FF Image (SHA256) Key source: Factory, External,Mixed Copyright © 2021, Diebold Nixdorf 14-3 01750356875A...
  • Page 57: Hdd Security Configuration

    Discard or Save changes option in setup does not have any impact on HDD when password is set or removed. If the ‘Set HDD User Password’ option is hidden, do power cycle to enable the option again. Copyright © 2021, Diebold Nixdorf 14-4 01750356875A...
  • Page 58: Boot

    15 Boot Copyright © 2021, Diebold Nixdorf 15-1 01750356875A...
  • Page 59 POST Phase End Beep: This POST phase end beep On/Off F10 Boot Menu: Enable/Disable hot key F10 to enter boot menu during POST Booting from USB Devices: Enable/Disable booting from USB Devices Copyright © 2021, Diebold Nixdorf 15-2 01750356875A...
  • Page 60 UEFI Hard Disk Drive BBS Priori- Specifies the Boot Device Priority sequence from available UEFI ties: Hard Disk Drives. UEFI NETWORK Drive BBS Pri- Specifies the Boot Device Priority sequence from available UEFI orities: NETWORK Drives. Copyright © 2021, Diebold Nixdorf 15-3 01750356875A...
  • Page 61: Uefi Hard Disk Drive Bbs Priorities

    Boot 15.1 15.1 UEFI Hard Disk Drive BBS Priorities Boot Option #1: Sets the system boot order. Copyright © 2021, Diebold Nixdorf 15-4 01750356875A...
  • Page 62: Uefi Network Drive Bbs Priorities

    Boot 15.2 15.2 UEFI NETWORK Drive BBS Priorities Boot Option #1: Sets the system boot order. Boot Option #2: Sets the system boot order. Copyright © 2021, Diebold Nixdorf 15-5 01750356875A...
  • Page 63: Exit

    Restore/Load Default values for all the setup options. Save as User Defaults: Save the changes done so far as User Defaults. Restore User Defaults: Restore the User Defaults to all the setup options. Copyright © 2021, Diebold Nixdorf 16-1 01750356875A...
  • Page 64: Certifications Of The Manufacturer

    The component has obtained the TÜV SÜD Bauart Mark (Type Tested Mark)” Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Responsible Party in the U. S.: Diebold Nixdorf Address: 5995 Mayfair Road, N. Canton, OH 44720 / USA Contact: cynthia.williams@dieboldnixdorf.com...
  • Page 65: Recycling

    For recycling purposes do not attach any additional adhesive labels to the terminal. Diebold Nixdorf disposes of old terminals in an environmentally responsible manner at a recycling center that is ISO 9001 and ISO 14001 certified, as is the entire company. Follow your local regulations on the disposal of toxic waste.
  • Page 66 DIEBOLD NIXDORF 5995 Mayfair Road | North Canton, OH 44720 | United States © 2021 Diebold Nixdorf, Incorporated. All Rights Reserved.
