R1/R2 Motherboard (with UEFI BIOS)
User manual
01750340075A
DieboldNixdorf.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R1 and is the answer not in the manual?

Questions and answers

Related Manuals for DIEBOLD NIXDORF R1

Summary of Contents for DIEBOLD NIXDORF R1

  • Page 1 R1/R2 Motherboard (with UEFI BIOS) User manual 01750340075A DieboldNixdorf.com...
  • Page 2 Copyright © Diebold Nixdorf All rights, including rights of translation, reproduction by printing, copying or similar methods, in part or in whole, are reserved. Any violations give rise to a claim for damages. All rights reserved, particularly in relation to the grant of a patent or the registration of a utility model.

  • Page 3: Table Of Contents

    11 Advanced Menu ......................27 11.1 Platform Misc Configuration ................27 11.2 CPU Configuration ...................28 11.3 System Agent (SA) Configuration ..............30 11.4 PCH Storage Configuration ................31 11.5 AMT Configuration (R1 only) ................32 11.6 Trusting Computing ..................33 11.7 Onboard Devices Configuration................34 11.8 APM Configuration ...................34...
  • Page 4 11.9 Serial Port Console Redirection (R1 only) ............35 11.10 Intel® TXT Information (R1 only) ..............37 11.11 USB Configuration....................37 11.12 Network Stack Configuration ................38 11.13 NVMe Configuration ..................39 11.14 HDD/SSD SMART Information .................39 11.15 Intel(R) Rapid Storage Technology ..............39 11.16 Intel(R) Ethernet Connection (7) I219LM ............39 12 Boot Menu ........................42...

  • Page 5: Symbols

    Symbols DANGER This warning note describes a hazard with a high degree of risk, which, if not avoided, will result in death or grave bodily injury. WARNING This warning note describes a hazard with a medium degree of risk, which, if not avoided, will result in death or grave bodily injury. CAUTION This warning note describes a hazard with a low degree of risk, which, if not avoided, will result in death or grave bodily injury.

  • Page 6: Warranty

    Warranty Generally Diebold Nixdorf guarantees a warranty engagement for 12 months beginning with the date of delivery. This warranty engagement covers all damages which occur despite a normal use of the product. Damages because of  improper or insufficient maintenance, ...

  • Page 7: Esd (Electrostatic Sensitive Devices)

    ESD (Electrostatic Sensitive Devices) Electrostatic sensitive devices (ESD) may be marked with this sticker. When you handle components fitted with ESDs, you must observe the following points under all circumstances:  Make sure that the device is de-energized before connecting, removing or installing com- ponents with ESD.

  • Page 8: Specifications R1-Motherboard

    Specifications R1-Motherboard Core™ i5/ i3, Pentium LGA1151 socket for 8th/9th Generation Intel® , and ® Celeron® processors Supports Intel® 14nm CPU * CPU only supports up to 65W. Chipset Intel® Q370 Chipset 2 x SO-DIMM, max.32GB, DDR4 2666*/2400/2133 MHz, non-ECC,...
  • Page 9 3 x SATA 6.0 Gb/s connectors 1 x CPU fan connector 1 x PSU fan connector 1 x Front panel header Front Panel I/O Ports 1 x 3-pin Clear RTC jumper 1 x Clear Password jumper 1 x 24-pin EATX power connector 1 x 4-pin ATX power connector 1 x 3-pin Chassis Intrusion connector 4 x USB 2.0 headers...

  • Page 10: Specifications R2-Motherboard

    Specifications R2-Motherboard LGA1151 socket for 8th/9th Generation Intel® Core™ i5/ i3, Pen- tium®, and Celeron® processors Supports Intel® 14nm CPU * CPU only supports up to 65W. Chipset Intel® H310 Chipset 2 x SO-DIMM, max.32GB, DDR4 2666*/2400/2133 MHz, non- ECC, unbuffered memory Dual-channel memory architecture Memory * DDR4 2666MHz and higher memory modules will run at max.
  • Page 11 3 x SATA 6.0 Gb/s connectors 1 x CPU fan connector 1 x PSU fan connector 1 x Front panel header Front Panel I/O Ports 1 x 3-pin Clear RTC jumper 1 x Clear Password jumper 1 x 24-pin EATX power connector 1 x 4-pin ATX power connector 1 x 3-pin Chassis Intrusion connector 4 x USB 2.0 headers...

  • Page 12: Motherboard Layout

    Motherboard Layout...
  • Page 13 Connectors/Jumpers/Slots Serial port connectors (12-1 pin COM2, COM3, COM4, COM5, COM6) LPT connector (26-1 pin LPT) ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) Intel ® LGA1151 CPU socket CPU and PSU fan connectors (3-pin PSU_FAN, 4-pin CPU_FAN) DDR4 SO-DIMM slots Serial ATA 6.0Gb/s connectors (7-pin SATA6G_0/2/3) System panel connector (12-1 pin F_PANEL) Clear password jumper (2-pin CLRPWD)

  • Page 14: Block Diagram

    Block diagram R1-Motherboard...

  • Page 15: R2-Motherboard

    R2-Motherboard...

  • Page 16: Central Processing Unit

    The motherboard comes with a surface mount LGA1151 socket designed for the 8th/9th Generation Intel® Core™ i5/ i3, Pentium®, and Celeron® processors. DN-300-R1/R2 CPU socket LGA1151 System Memory This motherboard comes with two Double Data Rate 4 (DDR4) Small Outline Dual Inline Memory Module (SO-DIMM) sockets.

  • Page 17: Jumpers

    Jumpers  Clear RTC RAM (3-pin CLRTC) This header allows you to clear the CMOS RTC RAM data. To erase the RTC RAM:  Turn OFF the computer and unplug the power cord.  Move the jumper cap from pins 2-3 (default) to pins 1-2. Keep the cap on pins 1-2 for about 5~10 seconds, then move the cap back to pins 2-3.
  • Page 18  Intel® ME Jumper (3-pin DIS_ME) This jumper allows you to enable or disable the Intel® ME function. Set this jumper to pins 1- 2 to enable (default) the Intel® ME function and to pins 2-3 to disable it. NOTICE Disable the Intel®...

  • Page 19: Connectors

     Clear password jumper (2-pin CLRPWD) Short the two pins, and press <F2> to enter BIOS at the next boot. The BIOS password will be removed. Connectors 8.3.1 Rear Panel Connectors 1. Serial port connectors (COM). These ports connect a modem, or other devices that conform with serial specification. 2.
  • Page 20 LAN Port LED Indications 5. Line In port (light blue). This port connects to the tape, CD, DVD player, or other audio sources. 6. Line Out port (lime). This port connects to a headphone or a speaker. 7. Microphone port (pink). This port connects to a microphone.

  • Page 21: Internal Connectors

    8.3.2 Internal Connectors 1. LPT connector (26-1 pin LPT) The LPT (Line Printing Terminal) connector supports devices such as a printer. LPT is stand- ardized as IEEE 1284, which is the parallel port interface on IBM PC-compatible computers. 2. USB 2.0 connectors (10-pin USB1_HUB, USB2_FRONT, USB3, USB4) These connectors are for USB 2.0 ports.
  • Page 22 3. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) Correctly orient the ATX power supply plugs into these connectors and push down firmly until the connectors completely fit. 4. CPU and PSU fan connectors (4-pin CPU_FAN, 3-pin PSU_FAN) Connect the fan cables to the fan connectors on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector.
  • Page 23 5. TPM connector (14-1 pin TPM) This connector supports a Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, pro- tects digital identities, and ensures platform integrity. 6.
  • Page 24  ATX power button/soft-off button (2-pin Power switch) This 2-pin connector is for the system power button.  Reset button (2-pin Reset) This 2-pin connector is for the chassis-mounted reset button for system reboot without turning off the system power. 7.
  • Page 25 9. Serial port connectors (12-1 pin COM2, COM3, COM4, COM5, COM6) These connectors are for serial (COM) ports. Connect the serial port cables to these connectors, then install the module to a slot opening at the back of the system chassis. 10.

  • Page 26: Raid

    11. LPC debug header This header allows connection to a LPC debug card. RAID This motherboard provides RAID functionality for the SATA interface. Raid level 0 (striping), 1 (mirroring) and 5 (striping with distributed parity) are supported. For RAID 5 three HDD/SSD devices are needed.

  • Page 27: Bios Setup Program

    BIOS Setup Program Use the BIOS Setup program to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief online help to guide you in using the BIOS Setup program. Entering BIOS Setup at startup To enter BIOS Setup at startup: Press <F2>...

  • Page 28: Self-Recovering Bios (After Bios Update)

    Self-Recovering BIOS (after BIOS Update) The BIOS protection technology automatically recovers the system’s BIOS with a verified backup in the event of an update failure, preventing the need to replace or reinstall your hardware. 9.3.1 How works the Self-Recovering BIOS? By using the EZFlash utility from Setup a verified backup of the BIOS (.cap) file is placed in a hidden area of your mass storage.

  • Page 29: Main Menu

    10 Main Menu The Main menu provides you an overview of the basic system information, and allows you to set the system date, time, and security settings. 10.1 System Date [Day MM/DD/YYYY] Allows you to set the system date. 10.2 System Time [HH:MM:SS] Allows you to set the system time.
  • Page 30 To clear the administrator password, follow the same steps as in changing an administrator password, but click OK when prompted to create/confirm the password. After you clear the password, the Administrator Password item on top of the screen shows Not Installed. Boot Menu Password If you have set a Boot Menu password, you must enter the password for accessing the Boot Menu.

  • Page 31: Advanced Menu

    11 Advanced Menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. 11.1 Platform Misc Configuration The items in this menu allow you to configure the platform-related features.

  • Page 32: Cpu Configuration

    DMI Link ASPM Control [Disabled] This item allows you to control the Active State Power Management on both CPU and PCH (platform controller hub) Both DMI link ASPM control items of the CPU and PCH sides must be enabled for the ASPM to take effect. Configuration options: [Disabled] [L0s] [L1] [L0sL1] PEG-ASPM [Disabled] This item allows you to select the ASPM state for energy-saving conditions, or use the opti- mized energy saving profile.
  • Page 33 Active Processor Cores [All] This item allows you to select the number of CPU cores to activate in each processor pack- age. Configuration options: [All] [1] [2] [3] [4] [5] NOTICE For some CPU types, only [All] and [1] appear. Hyper-threading [Enabled] The Intel Hyper-Threading Technology allows a hyper-threading processor to appear as two logical processors to the operating system, allowing the operating system to schedule two...

  • Page 34: System Agent (Sa) Configuration

    NOTICE The following items appear only when you set the CPU C-States to [Ena- bled]. Enhanced C-states [Enabled] [Enabled] Enables enhanced C1 state. [Disabled] Disables enhanced C1 state. CPU C3 Report [Enabled] Allows you to disable or enable the CPU C3 report to OS. Configuration options: [Enabled] [Disabled] CPU C6 Report [Enabled] Allows you to disable or enable the CPU C6 report to OS.

  • Page 35: Pch Storage Configuration

    Graphics Configuration Allows you to select a primary display from iGPU, and PCIe graphical devices. Primary IGFX Boot Display [BIOS Default] Select the Video Device to be activated during POST. Your selection does not take effect if you have installed an external graphics device. Secondary boot display selection will appear based on your selection.

  • Page 36: Amt Configuration (R1 Only)

    [Intel RST Premium With Intel Optane System Acceleration (RAID)] (R1 only) Set to [Intel RST Premium With Intel Optane System Acceleration (RAID)] when you want to create a RAID configuration from the SATA hard disk drives. Aggressive LPM Support [Disabled] This item is designed for LPM (link power management) support with a better energy saving conditions.

  • Page 37: Trusting Computing

    MEBx Selection Screen [Disabled] This item allows you to enable or disable this function. Configuration options: [Disabled] [En- abled] Un-Configure ME [Disabled] Sets this item to [Disabled] to unconfigure ME without using a password or set it to [Enabled] to use a password. Configuration options: [Disabled] [Enabled] 11.6 Trusting Computing TPM Device Selection [Firmware TPM] This item allows you to select the TPM device.

  • Page 38: Onboard Devices Configuration

    11.7 Onboard Devices Configuration Setup Mouse Support [Enabled] Configuration options: [Disabled] [Enabled] HD Audio [Enabled] [Enabled] Enables the HD Audio Device. [Disabled] Disables the HD Audio Device. Intel LAN Controller [Enabled] [Enabled] Enables the Intel LAN controller. [Disabled] Disables the controller. Serial Port Configuration The sub-items in this menu allow you to set the serial port configuration.

  • Page 39: Serial Port Console Redirection (R1 Only)

    Enables or disables Wake on PLink1 support. Configuration options: [Disabled] [S3] [S3/S4/ Wake on PLink2 [S3/S4/S5] Enables or disables Wake on PLink2 support. Configuration options: [Disabled] [S3] [S3/S4/ 11.9 Serial Port Console Redirection (R1 only) COM0 Console Redirection [Disabled] Allows you to enable or disable the console redirection feature. Configuration options: [Disa-...
  • Page 40 Parity [None] A parity bit can be sent with the data bits to detect some transmission errors. [Mark] and [Space] parity do not allow for error detection. [None] None [Even] parity bit is 0 if the num of 1’s in the data bits is even parity bit is 0 if num of 1’s in the data bits is odd [Odd] [Mark]...

  • Page 41: Intel® Txt Information (R1 Only)

    Microsoft Windows Emergency Management Services (EMS) allow for remote management of a Windows Server OS through a serial port. Configuration options: [None] [Hardware RTS/CTS] [Software Xon/Xoff] 11.10 Intel® TXT Information (R1 only) This menu displays Intel® Trusted Execution Technology (TXT) related information. 11.11 USB Configuration NOTICE The USB Devices item lists auto-detected values.

  • Page 42: Network Stack Configuration

    XHCI Hand-off [Disabled] NOTICE This item is set to [Disabled] by default for the EHCI (enhanced host controller interface) support by XHCI drivers in operating systems. [Disabled] Support XHCI by XHCI drivers for operating systems with XHCI support. [Enabled] Support XHCI by BIOS for operating systems without XHCI support. USB hardware delays and time-outs USB transfer time-out [20 sec] Allows you to select the USB transfer time-out value.

  • Page 43: Nvme Configuration

    11.13 NVMe Configuration This menu displays the NVMe controller and drive information of the connected devices. 11.14 HDD/SSD SMART Information This menu displays the SMART information of the connected devices. NOTICE NVM Express devices do not support SMART information. 11.15 Intel(R) Rapid Storage Technology This menu allows you to configure the RAID settings.
  • Page 44 Blink LEDs Identify the physical port by blinking the associated LED. Link Status [Disconnected] Displays the Ethernet connection status. Monitor menu The Monitor menu displays the system temperature/power status, and allows you to change the fan settings. CPU / MotherBoard Temperature [xxxºC/xxxºF] The onboard hardware monitor automatically detects and displays the CPU/ motherboard temperatures.
  • Page 45 PSU Fan Speed Low Limit [400 RPM] This item appears only when you enable the PSU Fan Q-Fan Control feature and allows you to disable or set the PSU Fan warning speed. Configuration options: [Ignore] [200RPM] [300 RPM] [400 RPM] [500 RPM] [600RPM] BAT Voltage Low Warning [Enabled] Allows you to set whether to show a warning message when the BAT voltage is getting low.

  • Page 46: Boot Menu

    12 Boot Menu The Boot menu items allow you to change the system boot options. Boot Configuration Boot Logo Display [Disabled] [Auto] Adjusts logo automatically based on Windows® display requirements. [Full Screen] Maximize the boot logo size. [Disabled] Hide the logo during POST. POST Delay Time [3 sec] This item appears only when you set Boot Logo Display to [Auto] and [Full Screen] This item allows you to select the desired additional POST waiting time to easily enter the BIOS setup.
  • Page 47 LED Error Codes Error Frequency RAM Error CPU Error Chipset Initialization Error UEFI/NVRAM error 0.5Hz GFX Error 0.25Hz CPU temperature too high 0.125Hz FAN speed below 400rpm 0.0625Hz Disabled Drive low The items below allow you to select whether to show the LED error codes. RAM Error LED [Enabled] Configuration options: [Disabled] [Enabled] CPU/Chipset Init Error LED [Enabled]...
  • Page 48 Clear Secure Boot keys This item appears only when you load the default Secure Boot keys. This item allows you to clear all the previously applied Secure Boot keys. Save all Secure Boot variables This item allows you to save all the Secure Boot keys to a USB storage device. PK Management The Platform Key (PK) locks and secures the firmware from any non-permissible changes.
  • Page 49 DB Management The db (Authorized Signature database) lists the signers or images of UEFI applications, op- erating system loaders, and UEFI drivers that you can load on the single computer. Save to File Allows you to save the downloaded db to a USB storage device. Set New Key Allows you to load the downloaded db from a USB storage device.
  • Page 50 Boot Option Priorities These items specify the boot device priority sequence from the available devices. The num- ber of device items that appears on the screen depends on the number of devices installed in the system. NOTICE To select the boot device during system startup, press <F8> when DN Logo appears.

  • Page 51: Tool Menu

    13 Tool Menu The Tool menu items allow you to configure options for special functions. Select an item then press <Enter> to display the submenu. EZ Flash 3 Utility This item allows you to run EZ Flash 3 utility. When you press <Enter>, a confirmation mes- sage appears.

  • Page 52: Exit Menu

    14 Exit Menu The Exit menu items allow you to load the optimal default values for the BIOS items, and save or discard your changes to the BIOS items. You can access the EZ Mode from the Exit menu. Load Optimized Defaults This option allows you to load the default values for each of the parameters on the Setup menus.

  • Page 53: Event Logs

    15 Event Logs A built-in event log enables easier troubleshooting by capturing useful system information. 15.1 Change Smbios Event Log Settings Allows you to change the Smbios event log configuration. Smbios Event Log [Enabled] Configuration options: [Disabled] [Enabled] Erase Event Log [No] Allows you to choose options for erasing Smbios Event Log.

  • Page 54: Certifications Of The Manufacturer

    The system is approved for the USA and Canada. Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Responsible Party in the U. S.: Diebold Nixdorf Address: 5995 Mayfair Road N. Canton, OH 44720 / USA Contact: cynthia.williams@dieboldnixdorf.com...

  • Page 55: Recycling

    For recycling purposes do not attach any additional adhesive labels to the terminal. Diebold Nixdorf disposes of old terminals in an environmentally responsible manner at a re- cycling center that is ISO 9001 and ISO 14001 certified, as is the entire company. Follow your local regulations on the disposal of toxic waste.
  • Page 56 Diebold Nixdorf D-33094 Paderborn Order No.: 01750299889B...

This manual is also suitable for:

R2
