Summary of Contents for DIEBOLD NIXDORF P1.0-APL-AIO

Page 1 P/Q-Motherboards User Manual 01750345464A...
Page 2: Table Of Contents
Main ........................8-2 8.1.3 Advanced ......................8-4 8.1.4 Chipset ........................ 8-27 8.1.5 PC Health......................8-35 8.1.6 Power ........................8-36 8.1.7 Security ....................... 8-38 8.1.8 Boot........................8-41 8.1.9 Save & Exit......................8-44 9 Recycling ............................ 9-1 Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 3: Symbols
This warning note describes a hazard with a low degree of risk, which, if not avoided, will result in death or grave bodily injury. NOTE This note provides application tips and information that help prevent errors and material damage. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 4: Important Notes
Before you install or remove any component, always remove the AC power by unplugging the power cord from the power outlet. Failure to do so may cause severe damage to the motherboard, peripherals, or components. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 5: Warranty
3 Warranty Generally Diebold Nixdorf guarantees a warranty engagement for 12 months beginning with the date of delivery. This warranty engagement covers all damages which occur despite a normal use of the prod- uct. Damages because of improper or insufficient maintenance, improper use of the product or unauthorized modifications of the product, inadequate location or surroundings will not be covered by the warranty.
Page 6: Esd (Electrostatic Sensitive Devices)
The equipment and tools you use must be free of static charges. Always hold boards with ESDs by their edges. Do not touch the components. Never touch pins or conductors on boards fitted with ESDs. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 7: Motherboard Variants
Figure 5-1: Px motherboard, front view, (Apollo Lake) 1 CMOS clear 2 Thermal pad 3 Heat sink 4 USB-R 5 SATA 6 SATA power 7 Speaker 8 Audio line-out 9 TPM option 10 M.2 2280 socket 11 SODIMM socket 12 USB-L Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 8: Back View
Motherboard Variants 5.1.2 5.1.2 Back view Figure 5-2: Px motherboard, back view, (Apollo Lake) 1 EDP port 2 NFC 3 Backlight 4 Touch 5 WLAN module 6 Front panel Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 9: Specification
Primary Display 14” TFT, 1920x1080, 6-bit+FRC M.2 2280 Socket M-Key SATA SSD User I/O Ports 1x USB-C Alt DP (PD2.0: 5V, 12V) 1x USB-C (5V) 2x USB3.0, 2x USB2.0 1x 24V-PUSB DVI/PL2 (secondary display) Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 11: Qx Motherboard
Figure 5-3: Qx motherboard, front view, (Kaby Lake) 1 CMOS clear 2 Thermal pad 3 Heat sink 4 USB-R 5 MF module 6 Speaker 7 M.2 2280 socket 8 SODIMM socket 9 TPM option 10 USB-L Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 12: Back View
Motherboard Variants 5.2.2 5.2.2 Back view Figure 5-4: Qx motherboard, back view, (Kaby Lake) 1 EDP port 2 NFC 3 Backlight 4 Touch 5 WLAN module 6 Front panel Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 13: Specification
M.2 2280 socket, M-Key SATA SATA & 4-Lane PCIe SATA & 4-Lane PCIe User I/O Ports 1x USB-C Alt DP (PD2.0: 5V, 12V) 1x USB-C (5V) 2x USB3.0, 2x USB2.0 1x 24V-PUSB DVI/PL2 (secondary display) Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 16: Qx-Motherboard
SPI0 CS2 TPM I/F USB2-6 & 7 Top/bottom USB2-8 Touch USB2-5 24V PUSB IT8613 Hub1-1 USB-L COM3 USB2 USB2-10 Hub1-3 BT/WIFI Hub1 Hub1-4 SMBUS Cash Drawer Hub2-1 USB2 USB2-9 Hub2-3 Capsense I/F USB-R Hub2 Hub2-4 Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 17: Apollo Lake
A UUID is an identifier standard used in software construction, standardized by the Open Software Foundation. The intent of the UUIDs is to enable distributed systems to uniquely identify information without significant central coordination. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 19 System Date: To set the date, use tab switch between date elements. Press numeric keys to enter. System Time: To set the time, use tab switch between time elements. Press numeric keys to enter. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 20: Advanced
Advanced The Advanced function in the system can be configured in this menu for advanced system configuration. Only change the default settings if required for a special purpose. Incorrect settings can cause malfunc- tion. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 22 Apollo Lake 7.1.3.2 7.1.3.2 Trusted Computing Secure Device Support: Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 25 IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 27 Power Limit 1 Enable: Enable/Disable Power Limit 1 programming. If this option is enabled, it activates the PL1 value to be used by the processor to limit the av- erage power of given time window. Copyright © 2021, Diebold Nixdorf 7-11 01750345464A...
Page 28 Power Limit 1 Power: A threshold for average platform power that will not be exceeded. Power Limit 1 Time Window: An averaging constant used for PL1 exponential weighted moving average (EWMA) power calculation. Copyright © 2021, Diebold Nixdorf 7-12 01750345464A...
Page 29 Maximum time the device will take before it properly reports itself to the Host Controller. AUTO uses default value: for a Root port, it is 100 ms. For a Hub port, the delay is taken from Hub descriptor. Copyright © 2021, Diebold Nixdorf 7-13 01750345464A...
Page 30 Apollo Lake 7.1.3.6 7.1.3.6 Security Configuration TXE MMRFPO: Intel Trusted Execution Engine Host ME Region Flash Protection Override. TXE EOP Message: Intel Trusted Execution Engine - for testing EOP (End of Post). Copyright © 2021, Diebold Nixdorf 7-14 01750345464A...
Page 32 Power Button Switch: Enable or Disable the Power Button Switch. Power Button Touch: Enable or Disable the Power Button Touch. Power Down Delay: Power Button Power Down mode. On-screen Controls: To enable On-screen control. Copyright © 2021, Diebold Nixdorf 7-16 01750345464A...
Page 33 Sets the Top Of Lower Usable DRAM. Above 4GB MMIO BIOS assignment: Enable high MMIO (above 4GB). PCIE VGA Workaround: Enable/Disable PCIE VGA Workaround. Primary IGFX Boot Display: Select which device may be used as primary display first. Copyright © 2021, Diebold Nixdorf 7-17 01750345464A...
Page 34 2048MB aperture. To use this feature, please disable CSM Support. DVMT Pre-Allocated: Select DVMT Pre-Allocated size.. DVMT Total Gfx Mem: Select DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device. IPU Enable/Disable: Enable/Disable IPU. Copyright © 2021, Diebold Nixdorf 7-18 01750345464A...
Page 36 Otherwise all drives spin up at boot. Port 1: Enable/Disable Port 1. SATA Port 1 Hot Plug Capability: Enable/Disable SATA Port 1 Hot Plug Capability. Copyright © 2021, Diebold Nixdorf 7-20 01750345464A...
Page 37 Apollo Lake South Cluster Configuration -> USB Configuration XHCI Pre-Boot Driver: Enable/Disable XHCI Pre-Boot Driver . xHCI Mode: Enable/Disable xHCI Mode USB Port Disable Override: Enable/Disable USB Port Disable Override. Copyright © 2021, Diebold Nixdorf 7-21 01750345464A...
Page 38 Enable/Disable the PCH BIOS Lock Enable feature. Required to be enabled to ensure SMM protection of flash. RTC Lock: Enable will lock bytes 38h-3Fh in the lower/upper 128-byte bank of RTC RAM. Flash Protection Range Registers: Enable/Disable Flash Protection Range Registers. Copyright © 2021, Diebold Nixdorf 7-22 01750345464A...
Page 39 Apollo Lake South Cluster Configuration -> OnBoard Device Configuration Wi-Fi Card: Enable/Disable Wi-Fi Card. Onboard Lan: Enable/Disable Onboard Lan. HD-Audio Support: Enable/Disable HD-Audio Support. Copyright © 2021, Diebold Nixdorf 7-23 01750345464A...
Page 41: Power
Enable/Disable USB S4 Wake up. LAN Wakeup support: Enable/Disable LAN Wakeup support. Wake Up on Alarm: Enables or Disables System wake up on alarm event. When en- abled, system will wake on the hr::min::sec specified. Copyright © 2021, Diebold Nixdorf 7-25 01750345464A...
Page 43 Force System to User Mode. Configure NVRAM to contain OEM-de- fined factory default Secure Boot Keys. Reset to Setup Mode: Reset to Setup Mode. Key Management: Enables expert users to modify Secure Boot Policy variables without full authentication. Copyright © 2021, Diebold Nixdorf 7-27 01750345464A...
Page 44 Restore DB defaults: Restore DB variable to factory defaults. Secure Boot Variables: Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST, b) EFI_CERT_X509 (DER encoded), c) EFI_CERT_RSA2048 (bin). Copyright © 2021, Diebold Nixdorf 7-28 01750345464A...
Page 45: Boot
Enables or disables Quiet Boot option. New Boot Option Policy: Controls the placement of newly detected UEFI boot options. Boot mode select: Select boot mode LEGACY/UEFI. FIXED BOOT ORDER Priorities: Sets the system boot order. Copyright © 2021, Diebold Nixdorf 7-29 01750345464A...
Page 47 Apollo Lake 7.1.8.2 7.1.8.2 UEFI NETWORK Drive BBS Priorities Boot Option #1: Sets the system boot order. Boot Option #2: Sets the system boot order. Copyright © 2021, Diebold Nixdorf 7-31 01750345464A...
Page 49 Enable/Disable Ipv4 HTTP Support:. Ipv6 PXE Support: Enable/Disable Ipv6 PXE Support:. Ipv6 HTTP Support: Enable/Disable Ipv6 HTTP Support:. PXE boot wait time: Select PXE boot wait time. Media detect count: Select Media detect count. Copyright © 2021, Diebold Nixdorf 7-33 01750345464A...
Page 50: Save & Exit
Legacy UEFI boot device will not appear in this list. You may over- ride the fixed boot priority order by selecting from this list the device to boot from. Alternatively, boot override can also be call out with the F10 hotkey. Copyright © 2021, Diebold Nixdorf 7-34 01750345464A...
Page 51: Kaby Lake
A UUID is an identifier standard used in software construction, standardized by the Open Software Foundation. The intent of the UUIDs is to enable distributed systems to uniquely identify information without significant central coordination. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 53 System Date: To set the date, use tab switch between date elements. Press numeric keys to enter. System Time: To set the time, use tab switch between time elements. Press numeric keys to enter. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 54: Advanced
Advanced The Advanced function in the system can be configured in this menu for advanced system configuration. Only change the default settings if required for a special purpose. Incorrect settings can cause malfunc- tion. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 55 Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious code attacks and prevent harmful soft- ware from executing and propagating on the server or network. Limit CPUID Maximum: Disabled for Windows XP Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 57 If this option is disabled, BIOS will program the default values for Platform Power Limit 2. Power Limit 4 Override: Enable/Disable Power Limit 4 Override. If this op- tion is disabled, BIOS will leave the default values for Power Limit 4. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 58 Core Ratio Limit must be greater than or equal to 1-Core Ratio Limit. Energy Efficient Turbo: Enable/Disable Energy Efficient Turbo feature. This feature will opportunistically lower the turbo frequency to increase efficiency. Recommended only to disable in overclocking. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 59 Power Limit 3 Settings Power Limit 3 Override: Enable/Disable Power Limit 3 Override. If this op- tion is disabled, BIOS will leave the default values for Power Limit 3 and Power Limit 3 Time Window. Copyright © 2021, Diebold Nixdorf 01750345464A...
Page 60 Identify the SATA Topology if it is Default or ISATA or Flex or DirectConnect or M2. SATA Port 2 DevSlp: Enable/Disable SATA Port 2 DevSlp. Board rework for LP needed before enable. DITO Configuration: Enable/Disable DITO Configuration. Copyright © 2021, Diebold Nixdorf 8-10 01750345464A...
Page 61 If enabled, indicates that the HDD password un- lock in the OS is enabled. LED Locate: If enabled, indicates that the LED/SGPIO hard- ware is attached and ping to locate feature is en- abled on the OS. Copyright © 2021, Diebold Nixdorf 8-11 01750345464A...
Page 64 PTT in SkuMgr Warning! PTT/dTPM will be disabled and all data saved on it will be lost. PTP aware OS: Select whether or not the OS you will boot to will be PTP aware. Copyright © 2021, Diebold Nixdorf 8-14 01750345464A...
Page 66 PROCHOT# will be driven. If bi-direction is enabled, external agents can drive PROCHOT# to throttle the processor. Disable PROCHOT# Output: Enable/Disable PROCHOT# output. Disable VR Thermal Alert: Enable/Disable VR Thermal Alert. Copyright © 2021, Diebold Nixdorf 8-16 01750345464A...
Page 67 Kaby Lake PROCHOT Response: Enable/Disable PROCHOT Response. PROCHOT Lock: Enable/Disable PROCHOT Lock. ACPI T-States: Enable/ Disable ACPI T-States. Copyright © 2021, Diebold Nixdorf 8-17 01750345464A...
Page 68 TPM 1.2 will restrict support to TPM 1.2 devices, TPM 2.0 will restrict support to TPM 2.0 devices, Auto will support both with the default set to TPM 2.0 devices if not found, TPM 1.2 devices will be enumerated. Copyright © 2021, Diebold Nixdorf 8-18 01750345464A...
Page 71 2048MB aperture. To use this feature, please disable CSM Support. DVMT Total Gfx Mem: Select DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device. Gfx Low Power Mode: This option is applicable for SFF only. Copyright © 2021, Diebold Nixdorf 8-21 01750345464A...
Page 72 Kaby Lake 8.1.3.9 8.1.3.9 Network Stack Configuration Network Stack: Enable/Disable UEFI Network Stack. Ipv4 PXE Support: Enable/Disable Ipv4 PXE Support. Ipv6 PXE Support: Enable/Disable Ipv6 PXE Support:. Copyright © 2021, Diebold Nixdorf 8-22 01750345464A...
Page 75 USB keyboard legacy support for non-USB aware Oses. USB transfer time-out: The time-out value for Control, Bulk, and Interrupt transfers. Device reset time-out: USB mass storage device Start Unit command time-out. Copyright © 2021, Diebold Nixdorf 8-25 01750345464A...
Page 76 Root port, it is 100 ms. For a Hub port, the delay is taken from Hub de- scriptor. Mass Storage Devices: This setting is visible if there are USB mass stor- age devices plugged in. Copyright © 2021, Diebold Nixdorf 8-26 01750345464A...
Page 77: Chipset
Kaby Lake 8.1.4 8.1.4 Chipset System Agent (SA) Configuration: System Agent (SA) Parameters PCH-IO Configuration: PCH Parameters MCU Configuration: MCU Parameters Copyright © 2021, Diebold Nixdorf 8-27 01750345464A...
Page 80 Kaby Lake 8.1.4.2 8.1.4.2 PCH-IO Configuration PCH LAN Controller: Enable/Disable PCH LAN Controller. LAN Wake From DeepSx: Enable/Disable LAN Wake From DeepSx. Copyright © 2021, Diebold Nixdorf 8-30 01750345464A...
Page 81 BIOS or OS. USB HS #3 USB4: USB HS #4 USB5: USB HS #5 USB6: USB HS #6 USB7: USB HS #7 Touch: USB HS #8 DVI/PL2 USB-R MF: USB HS #9 NFC USB-L BT: Copyright © 2021, Diebold Nixdorf 8-31 01750345464A...
Page 82 Enable will lock bytes 38h-3Fh in the lower/upper 128-byte bank of RTC RAM. BIOS Lock: Enable/Disable the PCH BIOS Lock Enable fea- ture. Required to be enabled to ensure SMM pro- tection of flash. Copyright © 2021, Diebold Nixdorf 8-32 01750345464A...
Page 84 Power Button Switch: Enable or Disable the Power Button Switch. Power Button Touch: Enable or Disable the Power Button Touch. Power Down Delay: Power Button Power Down mode. On-screen Controls: To enable On-screen control. Copyright © 2021, Diebold Nixdorf 8-34 01750345464A...
Page 86: Power
3) Last State DeepSx Power Policies: Enable/Disable DeepSx Power Policies. Wake on LAN Enable: Enables or Disables System wake up on LAN event. USB Wake up: Enable/Disable USB Wake up. WIFI Control: WIFI Control, Enabled/Disabled. Copyright © 2021, Diebold Nixdorf 8-36 01750345464A...
Page 89 8.1.7.1 8.1.7.1 Secure Boot Attempt Secure Boot: Enable/Disable Attempt Secure Boot. Secure Boot Mode: Secure Boot is activated when Platform Key (PK) is enrolled, System mode is User/Deployed, and CSM function is disabled. Copyright © 2021, Diebold Nixdorf 8-39 01750345464A...
Page 90 Authorized Signatures: b) EFI_CERT_X509 (DER encoded) Forbidden Signatures: c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHA256, 384, 512 Authorized TimeStamps: 2. Authenticated UEFI Variable 3. EFI PE/COFF Image (SHA256) OsRecovery Signatures: Key Source: Default, External, Mixed, Test Copyright © 2021, Diebold Nixdorf 8-40 01750345464A...
Page 91: Boot
Controls the placement of newly detected UEFI boot options. Boot mode select: Select boot mode LEGACY/UEFI. Boot Option #1: Boot Option #2: Boot Option #3: Sets the system boot order. Boot Option #4: Boot Option #5: Copyright © 2021, Diebold Nixdorf 8-41 01750345464A...
Page 93 Kaby Lake 8.1.8.2 8.1.8.2 UEFI NETWORK Drive BBS Priorities Boot Option #1: Sets the system boot order. Boot Option #2: Sets the system boot order. Copyright © 2021, Diebold Nixdorf 8-43 01750345464A...
Page 94: Save & Exit
Save the changes done so far as User Defaults. Restore User Defaults: Restore the User Defaults to all the setup options. Launch EFI Shell from filesystem Attempts to Launch EFI Shell application (Shell.efi) from one of the device: available filesystem devices. Copyright © 2021, Diebold Nixdorf 8-44 01750345464A...
Page 95: Recycling
The processed plastics can, for the most part, be recycled. Even the precious metals can be recovered. Diebold Nixdorf guarantees the environmentally safe disposal of these parts in a Recycling Center, which is certified pursuant to ISO 9001 and ISO 14001.
