Summary of Contents for Broyhill SHORELINE A222002904
- Page 1 ASSEMBLY INSTRUCTIONS ITEM#: A222002904 SKU#: 810494407 SHORELINE 2PK DEEP SEAT CLUB CHAIRS Need help? We are here for you! 1(866)578.6569 24/7 ・ Toll Free...
- Page 2 GENERAL BEST PRACTICES FOR ASSEMBLY: • Please read and understand this entire manual before attempting to assemble or install the product. • Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list.
- Page 3 EXPLODED DRAWING...
- Page 4 PARTS LIST Label Description Part Image Part Number P001500040 Back P001600030 Seat P001800106 Cushion P001700003 Back Cushion Foot pad P005300053 Pre-assembled HARDWARE LIST Label Part Number Description Part Image Bolt M6*20 Flat washer H050010025 Flat washer H090010017...
- Page 5 HELPFUL HINTS • Tools needed and not included • Separating parts before starting Provided in hardw are pack Provided How many people needed for the installation work...
- Page 6 STEP 1 Assembled View: Attached Back (A) to Seat (B) with Bolt (H1) and Flat washer(H2), tighten all the Bolt to 100% depth with Wrench(HW) at last.
- Page 7 STEP 2 Assembled View: Put the Seat Cushion(D) on the Seat(B).
