1. Introduction

The HS11 is designed as a heavy-duty heat-seal machine for applying patches,
emblems, hot paper transfers and identification tapes. The sealing cycle is initiated
by hand, which causes the sealing head to lower. Temperature, time and sealing
pressure can all be individually adjusted as required for the particular materials
being sealed. Upper and lower platen temperatures can be set independently in
Fahrenheit or Celsius. A new LCD screen with a 3-button interface simplifies
machine operation.
The machine develops 24 PSI inter-platen pressure with the standard 5" x 6"
platens. Two optional smaller platens are available for even higher inter-platen
pressure.

1.1 What Did You Receive?

HS11 Machine
Line Power Cord

1.2 Machine Specifications

Electrical requirements
Maximum operating air pressure : 70 PSI (4.8 Bar)
Time settings
Heat range
Shipping weight
Length (open)
(closed)
Height
Width
Sealing iron size
Sealing pad size (standard)
Pedestal (optional)
Garment tray (optional)
Air Filter Pressure Regulator
Quick Start Guide
(optional)
(optional)
: 32" (81 cm) high
: 17" x 25" (43 x 64 cm)
5
Air Line Hose
Instruction Manual CD
: 12 amp @ 120 VAC, 50/60Hz or
6.0 Amp @ 240 VAC, 50/60Hz
: 1.0-30 seconds
: 150º-450ºF (66º-232ºC)
: 65 lbs (29.5 kg)
: 20" (51 cm)
: 23" (58 cm)
: 21" (53 cm)
: 8" (20 cm)
: 5" x 6" (13 x 15 cm)
: 5" x 6" (13 x 15 cm)
2" x 4" (5 x 10 cm)
1-3/16" x 4" (3 x 10 cm)
