Docking Station,
3.5"/2.5" HDD SATA
Art.no 38-4121
Model ZH3519
Please read the entire instruction manual before using the product
and save it for future reference. We reserve the right for any errors
in text or images and any necessary changes made to technical
data. If you have any questions regarding technical problems
please contact Customer Services.
Safety
•
Unplug the mains adaptor from the power supply before
cleaning. Wipe the product with a lightly moistened cloth
when required; never use solvents or strong detergents.
•
Do not place the product where it can fall into water or
other liquids. Do not place any objects containing liquid on
top of the product, e.g. vases or drinks.
•
Place the product on a smooth surface where there is little
risk of it falling. Protect it from unwanted shocks and impacts.
•
Use only the included mains adaptor.
•
Make sure the lead from the adaptor is not damaged in any way.
•
The mains adaptor must not be used if any part is damaged,
it should be discarded or repaired by a qualified electrician.
•
The docking station or mains adaptor must not be
disassembled or modified in any way.
•
The product may not be used if any part is damaged, it should
either be discarded or repaired by a qualified repairman.
Contents
•
Docking station
•
Mains adaptor
•
USB 3.0 cable
•
Instruction manual
GREAT BRITAIN • customer service tel: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk
Product description
Top
2
1
3
4
5
1. For 3.5" hard drive
2. For 2.5" hard drive
3. Docking station
4. Release catch for removing had drive from docking station
5. LED
Back
6 7
8
6. On/off switch
7. AC/DC mains adaptor
8. USB port for computer
Use
1. Make sure that the docking station is switched off.
2. Connect the adaptor to a wall socket.
3. Connect the supplied USB cable between
the docking station and a computer.
4. Insert a hard drive into the docking station.
5. Turn the docking station on.
6. Always turn the docking station off before removing
the hard drive. Then press in the release catch and
remove the hard drive.
Care and maintenance
Clean the product by wiping it with a soft dry cloth.
Disposal
Follow local ordinances when disposing of this product.
If you are unsure of how to dispose of this product,
please contact your local authority.
Specifications
Requires Windows XP, Vista (32/64-bit), Windows 7 (32/64-bit),
Windows 8 (32/64-bit) and Windows 10 (32/64-bit)
MAC OS 10.3 and later
Interface USB 3.0
Max. 3 Gbps
Mains adaptor 12 V/2 A
