Summary of Contents for ShowTex widescreen 600 regular
- Page 1 widescreen 600 regular...
- Page 2 INSTRUCTION MANUAL WIDESCREEN 600 regular Permanently installed system WARNING: Important safety instructions. It is important for the safety of persons to follow these instructions. Save these instructions. WIDESCREEN 6OO Class I Index Protection: IP44 Torque: 25 Nm Speed: 17 rpm...
- Page 3 WIDESCREEN 600 regular BIG LODO EVOLUTION Permanently installed system PERMANENTLY INSTALLED LARGE SIZE SYSTEM Wall and ceiling brackt n. 2 units (included) Wall and ceiling bracket n. 2 units (included) 236,6 B ( 1 : 2 ) 28,4 23,9 249,5 SCREEN LINE S.r.l.
- Page 4 WIDESCREEN 600 regular BIG LODO EVOLUTION PERMANENTLY INSTALLED LARGE SIZE SYSTEM Permanently installed system Safety chains n.2 units (included) Safety chains n. 2 units (included) Easy quick regulation of the counterweight in case of waves on the fabric. Easy quick regulation of the counterweight in case of waves on the fabric.
- Page 5 WIDESCREEN 600 regular Permanently installed system � � SAFETY SAFETY CHAINS CHAINS www.showtex.com...
- Page 6 WIDESCREEN 600 regular Permanently installed system The PVC fabric is very sensitive to heating. In a very hot environment the fabric can soften excessively and WARNING stretch down by altering the video ratio. You should absolutely avoid placing the screen in front of sunlit windows or above radiators, fireplaces and stoves of all kinds.
- Page 7 4 x 0,75 mm 4 x 0,75 mm 4 x 0,75 mm 4 x 0,75 mm 3 x 1,5 mm 3 x 1,5 mm WARNING 3 x 1,5 mm 3 x 1,5 mm • The drive shall be disconnected from its power source during cleaning, maintenance and when replacing parts.
