- Page 1 S howTex Use r Manual HiSpe ed R ol l Up...
- Page 2 Ta bl e o f C o nt e n ts Introduction Safety Instructions Component Assembly Connect the motor to the axis Suspend the roll up Connect the cables Power up the HSRU system Set the soft limits Program with the remote unit Program with the control panel on the motor-unit Switch to DMX Test the general system operation...
- Page 3 In tro duc t io n · The HiSpeed Roll-Up (HSRU) is a motor driven roll up system with a fast roll up speed of 2m/second. · The screen is attached to a 3m, 6m or 9m cylinder and installed in a 20/40 truss. ·...
- Page 4 Safe ty Ins t r uc t io ns · Read this user manual carefully. · The roll up system may only be used to move curtains and screens. Never use this system to move people, animals, or any other heavy objects. ·...
- Page 5 C o m po ne nt Pa r t s The HSRU system consists of the following parts: HSRU System Motor Unit Truss Emergency Unit Remote Unit Power Supply Cable Emergency Stop Cable DMX Cable Isolation Transformer Truss-Trolley Sh ow Tex U s er M anu a l HS RU...
- Page 6 C o m po ne nt Pa r t s Name Art.nr. Colour Weight Information Diameter As Motor Unit 8140 3112 0017 100 kg/piece Truss 8140 3115 3007 125 kg/piece Length: 300 cm 200 mm 8140 3115 6007 160 kg/piece Length: 600 cm 200 mm 8140 3115 9007...
- Page 7 As s em bl y In order for t h e system to op erate corre c tl y t h e follow in g ste p s s ho uld b e t ake n : Connect the motor to the axis If these are already connected go to step 2.
- Page 8 As s em bl y Power Input Emergency Remote Control Stop Input On / Off Emergency DMX / Man Stop Link Drive Ready DMX In Reset DMX Out Up / Down Slow / Fast Connecting the cables • Plug the Emergency Stop Unit into the “Emergency Stop Input” (7 pin XLR) •...
- Page 9 As s em bl y Starting the HSRU system Disengage the “Enable”-button and release the Emergency Stop on the Emergency Stop Unit. Set the switch on the motor unit to ‘Manual’ and press the ‘On/Off’ button to start up the motor. When the roll-up system has started, the green ‘On/Off’...
- Page 10 As s em bl y Setting the soft limits • The system has soft limits and hard limits.The hard limits determine the absolute safe limits (UP/DOWN) allowed by the system. The soft limits are always within the boundaries of the hard limits and are determined Hard Limit UP and set by the user.
- Page 11 As s em bly Setting the soft limits with the control panel of the motor-unit Roll the screen down, using the “Up/Down” button on the motor-unit until the screen is at the desired lowest point. Press the button until “soft limit min” appears on the screen.Then press the and the button at the same time, and confirm the position by pushing the...
- Page 12 As s em bl y Test the system’s general operation. Attention: Always ensure that the Emergency stop controller“Enable”-button is disengaged before performing system maintenance. Disassembling the HSRU system Set the switch on the motor-unit to manual. Position the screen to the transport position. To do this, roll up the screen to its top hard limit by using the “Up/Down”-button.
- Page 13 C are and Ma i nte na nce · The High Speed Roll Up system has components that must be regularly checked, maintained, and replaced in order to ensure safety and keep it in good condition. · The best way to maintain the HSRU system is to use it often. Each mechanical part should be used at least once a week.
- Page 14 · Wait 30 seconds before releasing the emergency stop to prevent regulator damage (see STEP 4). For more technical assistance please contact your local ShowTex office. (see back cover of manual ) H AVE A GRE AT S HOW! S howTex U s er Manual H SR U...
- Page 15 www. s howt e x. c om...
