8.2

CONNECTING AND PUTTING A BASE STATION IN SERVICE

8.2.1

INSTALLING A BASE STATION

Locate the radio base station as determined by the site survey deployment. Any deviation
by 1 or 2 meters may jeopardize the performances on the site or on one or more floors.
As far as possible, avoid installing base stations on large concrete structures (supporting
walls) or close to large metallic surfaces.
Note: Certain elements may obstruct the radio propagation signal.
PAGE 96/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.

Figure 23: Radio base station (cover removed)
