8. INTEGRATED DECT BASE STATION MC 6241

The DECT base station is connected to MC 6500 PBXs via a S0 bus using two twisted
pairs and a third pair for synchronization if necessary. This S0 bus is connected to an ISDN
S0 interface card in the PBX.
8.1

GENERAL

The DECT radio base station MC 6241 is housed in a plastic shell. Do not apply paint to the
shell unless you have received written agreement from Marta Nortel Communications.
The DECT radio base station MC 6241 can manage two or four radio channels.
For 2/4 channel compatibility, use a base station with index reference RB1734E or later.
2-channel radio base station
The connection interfaces for 2-channel radio base stations must be configured in S0
mode, with the remote power supply in service.
4-channel radio base station
Signal processing functions for this radio base station are performed remotely in the PBX.
In this case, the S0 interface transports four 32 Kb/s ADPCM coded communications as
well as the 16 Kb/s signaling channel.
Four-channel base stations require ADPCM daughter cards to be fitted on the PBX
interface cards. These cards provide ADPCM encoding/decoding thereby allowing
transmission of two DECT channels in the S0 interface B channel.
The connection interfaces must be configured in S0 mode, with the 48 V remote power
supply in service.
8.1.1

CLIMATIC CONDITIONS

The following climatic conditions apply to the DECT base station:
In operation:
♦
Temperature:
♦
Relative humidity:
Storage:
♦
Temperature range:
♦
Relative humidity range: from 10 to 90%, without condensation.
If required you can use a special cabinet allowing both frost free (-20°C) and high
temperature (+60°C) control and housing of the radio base station.
PAGE 94/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
from 5 to 45 °C.
from 10 to 80%, without condensation.
from -10 to 60 °C.
