7. CONNECTING DECT RADIO BASE STATIONS TO F4 PBXs

7.1

PRESENTATION

The F4 range includes the following PBXs:
♦
MC 6550
♦
MC 6550-LC
♦
MC 6550 L
♦
MC 6530
♦
MC 6530E
The following S0 interface cards is used to connect DECT radio base stations for the
F4 range:
♦
LDSA or LDSB cards
♦
LAS card
The description and configuration of these cards are as the same as for the F2 range. See
the section concerned.
7.2

REFERENCES AND EQUIPMENT

LDS cards
LDSA
LDSB
LDS daughter card
ADPCM
Plug
BADX
PAGE 86/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
Designation
16 T0/S0 interfaces, 2/4-channel DECT radio base stations
8 T0/S0 interfaces, 2/4-channel DECT radio base stations
Designation
ADCPM daughter card for the LDS card is used for management of
4-channel base stations (1 card for 2 interfaces)
Designation
Synchronous bus link plug
HJ4094A
HJ4094B
HJ4055A
HR5124B
LCAH-30521-001-05=01/EN
Reference
Reference
Reference
