4.4.3

CONNECTING RADIO BASE STATIONS

Figure 18: Connecting radio base stations to the LS1 card

Note: RT: T-interface (receive)
AND: T-interface (transmit)
Remark
Note: Do not connect other ISDN equipment to the S0 interface.
4.4.4

BASE STATION POWER SUPPLY

Bases stations are remotely powered from the S0 interface.
PAGE 64/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
Respect polarity of the clock and the Rx/Tx pairs.
RS: S-interface (receive)
ES: S-interface (transmit)
LCAH-30521-001-05=01/EN
