3.2.3

DESCRIPTION OF SWITCHES

CA1-2-3-4 - S0 bus type adaptation
•
OFF position:
•
ON position:
•
If the bus is configured as T0, leave this switch set to the ON position (as
delivered from the factory)
CA5 - Configuration of port J6-J8
•
OFF position:
•
ON position:
CA6 - Starting up internal battery (PL1) for data back up
•
OFF position:
•
ON position:
CA9-1 - NMI (reserved for factory tests)
CA9-2 - Reset
•
OFF position:
•
ON position:
position).
CA10 - S0 interfaces 40 V remote power supply for S0 buses
•
Position 1-2
•
Position 9-10
•
Position 2-3
•
Position 10-11
•
Position 3-4
•
Position 11-12
•
Position 5-6
•
Position 13-14
•
Position 6-7
•
Position 14-15
•
Position 7-8
•
Position 15-16
CA11 - CT2 - DECT clock (CA11-1: CT2 - CA11-2: DECT = not used)
•
OFF Position:
•
ON position:
LCAH-30521-001-05=01/EN
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONSet ne doit pas être reproduit ou communiqué sans autorisation.
Y Bus
Bus in line (short, extended or point-to-point)
T0 configuration (as delivered from the factory)
S0 configuration
Battery disabled (as delivered from the factory)
Battery enabled → to be set to the ON position on first start up
No RESET
System RESET (do not leave this switch set to the ON
S0 bus (2.1) not remotely powered (as delivered from the
}
factory)
}
S0 bus (2.1) 40 V remote power supply
}
S0 bus (2.1) 48 V remote power supply
}
S0 bus (3.1) not remotely powered (as delivered from the
factory)
}
S0 bus (3.1) 40 V remote power supply
}
S0 bus (3.1) 48 V remote power supply
No clock signal (as delivered from the factory)
Clock signal sent to EOCC card
