3.1.6
EOCT CARD
3.1.6.1
PRESENTATION
The EOCT card has two interfaces that can be configured as T0 or S0. This card is fitted to
connector J3 on the OCZ card.
J1
MN3
3.1.6.2
DESCRIPTION OF THE CONNECTORS
Name
J2, J3
J4, J5
PAGE
30/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
SW3
SW8
SW9
SW10
Two 2-pin connectors for connecting equipment 0.
Each Tx/Rx pair of the ISDN interface is polarized.
Under no circumstances should the polarity of the wires
be reversed.
Two 2-pin connectors for connecting equipment 1.
Each Tx/Rx pair of the ISDN interface is polarized.
Under no circumstances should the polarity of the wires
be reversed.
SW5
SW4
Function
LCAH-30521-001-05=01/EN
J3
T0 / S0
J2
J5
T0 / S0
J4
