Matra Nortel MC 6500 Manual page 124

Example of the screen display
Object=Cells
------------------------------------------------------------
Type of cell=DECT
------------------------------------------------------------
Location zones--->
9.3.7.2 DECLARING DECT PARAMETERS
To declare DECT parameters, use the MMC XLIGAB, and select the "Radio restrictions"
object and the "DECT parameter" subobject.
Define the following parameters:
♦
PARI 1: mandatory, 10 digits maximum, in decimal, from cell 1 to cell 32
♦
PARI 2: optional, 10 digits maximum, in decimal, from cell 33 to cell 64
♦
PARI 3: optional, 10 digits maximum from cell 65 to cell 96
♦
PARI 4: optional, 10 digits maximum from 97 to cell 128
The PARI number identifies the system. This number is always indicated on a label fixed
to the cabinet (for new systems). Only the PARI 1 number (1 to 32 cells) must be
supplied.
♦
RS
This mandatory parameter is used to identify the mobile during registration. It
contains 10 digits maximum, zero (0) is not allowed.
♦
RAND f
This mandatory parameter is used like the RS to identify the mobile during
registration. It contains 10 digits maximum, zero (0) is not allowed.
RS and RAND f are two random values (that must be different) registered in the mobile by
the PBX when the mobile is registered in the DECT system. From this point onwards, the
PBX regularly checks the values registered in the mobiles (the values are calculated from
these two parameters) to authorize or refuse use of the DECT network.
Enter a value lower than 4294967295 (FFFF FFFFh). The value of the random number has
no significance. However, in a multi-site configuration the number must be identical in all
locations where the mobiles will be registered.
♦
LLP Radst profix: this mandatory parameter has 4 digits (maximum) and is and
used for downloading to radio base stations. Allocate the value 999 by default. The
PLL directory number is composed of a prefix code followed by the base station
declaration order number. Example: 999000, 999001, 999002, etc
The base stations are connected to the PBX via an S0 Basic Rate Interface. One
PLL (D channel) is used for signaling and downloading to the base stations. PLL
directory numbers are comprised of digits recorded in this parameter followed by
the base station declaration order number.
PAGE 124/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
CORDLESS TOPOLOGY
=0.
Action=Display
Cell=3..
LCAH-30521-001-05=01/EN
