9.3.6.3 CHECKING CARD STATUS
When the card has been put in service, use the MMC XETBLS and check the SBL status
using the Display option.
Example of a screen display
Object= SBL STATUS
------------------------------------------------------------------
SBL family=BOARDS
Board number=2
------------------------------------------------------------------
------------------------------------------------------------------
Board Type=LDS (32 TS)
-----------------------------------------------------------------
9.3.7 DECLARING THE TOPOLOGY
9.3.7.1 DECLARING CELLS (SINGLE COMPANY CONFIGURATION)
TO declare cells, use the MMC XCELLU. This cell allows you to:
♦
define radio zones
♦
break down zones into cells
The geographical area for the radio coverage of a system may include one or more cells. In
a multisite configuration, radio coverage zones may overlap with cells located where radio
coverage zones intersect. You are recommended to define a uniform plan for the allocation
of cell numbers for a multisite system.
The radio coverage of a cell is provided by one or more radio base stations (8 maximum).
However, you are recommended to provide a margin for any future expansion in traffic by
allocating no more than 6 base stations in a call.
To declare a DECT cell in single company configuration, define the following parameters:
♦
type of cell: DECT
♦
cell: 0 to 126
♦
location zone: 0
Note: The MMC XCELLU does not have the CREATE action. A cell is created by
allocating a zone number and deleted by not allocating a zone number.
LCAH-30521-001-05=01/EN
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONSet ne doit pas être reproduit ou communiqué sans autorisation.
SBL STATUS
SBL status=IN SERVICE
Software Variant=23
Action=Display
CCU=3.
SBL sub-family=CLX
Synchronous bus number =4.
