9.2.3.2 DECLARING CELLS (MULTI-COMPANY CONFIGURATION)
This screen allows you to declare cells that were previously defined during deployment.
The maximum number of cells is set to one hundred and twenty-eight (128).
MENU: 1.9.2.1
9.2.3.3 DECT PARAMETERS
MENU: 1.8.1.2 or 1-9-1.2 (for multi-company configuration)
PARI VALUE 0
RANDOM VAL RECORDED
RS VAL RECORDED
DIR. BEGINNING ASSIGNED TO PLL
SEARCH MOBILES NOT REGISTERED
IN THE LOCAL SITE
OR IN OTHER SITE
OR IN THE LOCAL CENTER
OR IN ANOTHER CENTER
OR IN THE LIST
PARI VALUE: 9 digits maximum (automatically limited by the system to avoid exceeding
capacity).
RANDOM VAL RECORDED and RS VAL RECORDED: 9 digits maximum.
Two random values (that must be different) registered in the mobile by the PBX when the
mobile is registered in the DECT system. From this point onwards, the PBX regularly
checks the values registered in the mobiles (the values are calculated from these two
parameters) to authorize or refuse use of the DECT network.
Enter a value lower than 4294967295 (FFFF FFFFh). The value of the random number has
no significance. However, in a multi-site configuration the number must be identical in all
locations where the mobiles will be registered.
DIR. BEGINNING ASSIGNED DIRECTORY TO PLL: 4 digits maximum, 999 by default.
The base stations are connected to the PBX via an S0 Basic Rate Interface. One PLL (D
channel) is used for signaling and downloading to the base stations. PLL directory numbers
are comprised of digits recorded in this parameter followed by the base station declaration
order number.
Example: 999000, 999001, 999002, etc.
Note: REGISTRATION SITE - for a multi-site configuration, additional parameters will
appear allowing you list the sites on which the mobile sets will be registered.
PAGE 106/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
NAMES OF CELLS
CELL 0
CELL 1
CELL 2
CELL 3
CELL 4
DECT PARAMETERS
BLDG A...
BLDG F...
JPT.....
........
........
0........
0........
0........
999
YES
........
NO
........
........
LCAH-30521-001-05=01/EN
