8.4 SIGNALING CHANNEL
The processor for the PBX S0 interface card and the card microcontroller communicate via
D-channel of the S0 interface.
The D-channel is used for downloading to the radio base station and for signaling
exchanges.
8.5

RADIO BASE STATION LED INDICATIONS

When the radio base station has been installed, a Light Emitting Diode (LED) displays the
following statuses:
LED OFF
LED ON
Slow blink
Fast blink
LCAH-30521-001-05=01/EN
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONSet ne doit pas être reproduit ou communiqué sans autorisation.
Base station is not powered
Base station is powered.
Base station is out of service.
Base station is loaded. Link with PBX is operational.
If DECT synchronization is operational, radio base
station is operable.
Base station is operating and communication is
established between the two ISDN channels.
