GE JGRP20 Installation Instructions Manual

24” gas built-in oven.
Hide thumbs

Advertisement

Installation
Instructions
Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: www.GEAppliances.com
BEFORE YOU BEGIN
Read these instructions and warnings
completely and carefully.
IN THE COMMONWEALTH
OF MASSACHUSETTS:
• This product must be installed by a licensed
plumber or gas fitter.
• When using ball-type gas shut-off valves,
they shall be the T-handle type.
• A flexible gas connector, when used, must
not exceed 3 feet.
IMPORTANT
instructions for local inspector's use.
IMPORTANT
governing codes and ordinances.
IMPORTANT
appliance shall be conducted according to
the manufacturer's instructions.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these
instructions for future reference.
• Skill level – Installation of this appliance
requires basic mechanical skills.
• Completion time – 1 to 3 hours
• Proper installation is the responsibility
of the installer.
• Product failure due to improper installation
is not covered under the Warranty.
WARNING
be properly grounded.
4053P578
229C
31-10584
12-03 JR
— Save these
— Observe all
— Leak testing of the
— This appliance must
24" Gas
Built-In Oven
JGRP20
FOR YOUR SAFETY:
WARNING
in this manual is not followed exactly, a fire,
explosion or gas leak may result, causing
property damage, personal injury or death.
DO NOT STORE OR USE GASOLINE OR
OTHER FLAMMABLE VAPORS AND LIQUIDS
IN THE VICINITY OF THIS OR ANY OTHER
APPLIANCE!
WHAT TO DO IF YOU
SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
• Be sure your oven is installed properly by
a qualified installer or service technician.
• Be sure the oven is securely installed in a
cabinet that is firmly attached to the house
structure. Weight on the oven door could
cause the oven to tip, resulting in serious
personal injury or death. Never allow
anyone to climb, sit, lean, stand or hang
on the oven door.
1
— If the information

Advertisement

   Also See for GE JGRP20

   Related Manuals for GE JGRP20

   Summary of Contents for GE JGRP20

  • Page 1: Installation Instructions

    Installation Instructions Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: www.GEAppliances.com BEFORE YOU BEGIN Read these instructions and warnings completely and carefully. IN THE COMMONWEALTH OF MASSACHUSETTS: • This product must be installed by a licensed plumber or gas fitter.

  • Page 2: Installation Instructions, Tools You Will Need, Electrical Requirements

    National Energy Conservation Policy Act of 1978 and the National Appliance Energy Conservation Act of 1987. If the oven is to be installed in a mobile home, the installation must conform to the Manufactured Home Construction and Safety Standard, Title 24, CFR, Part 3280 or,...

  • Page 3: Prepare The Opening, Special Notes

    (See Fig. 2) It’s best to use a template to make a straight cut. Place the template on a level base line, 22″ to 28″ above the floor. This will place the oven cavity 36″ or 42″ above the floor. 24″...

  • Page 4: Electrical Connections, Gas Connections

    INSTALL THE OVEN ELECTRICAL CONNECTIONS An adequate electrical supply and outlet must be used to operate the electrical parts of your oven. The oven cord has a three-prong plug and must be used with a properly grounded three-hole outlet with a standard 120 Volt, 60 cycle AC household current.

  • Page 5

    Installation Instructions GAS CONNECTIONS (cont.) Place the oven in the cutout. Level the oven: 1. Place a spirit level on one of the oven racks. 2. If the oven is not level, adjust the leg levelers. 3. Remove regulator cover at the back of the storage drawer area by removing 4 screws.

  • Page 6

    To properly check the bake burner, the oven bottom and oven baffle must be removed. Turn on the bake or broil burner. As you watch the flame with the oven door...

  • Page 7

    Using a 1/8″ drill bit, drill holes through the side trim and into the cabinet front. With the screws provided, secure the oven to the wall. If the cabinet cutout is 38″ high, use the short trim and attach to the bottom of the front frame, with screws provided.

  • Page 8

    Unscrew the cap. Gasket Fig. 12 NAT. NAT. Installation Instructions Your Broil burner is located in the upper portion of the oven and is easilly accessible. To access your Bake burner follow the steps below: Regulator Cover Spring Retainer Air Shutter L.P.

  • Page 9

    Turn on the bake or broil burner. Broil Burner As you watch the flame with the oven door closed, check the following through the oven door window: Burner flames should not flutter or blow away from the burner.

  • Page 10

    Make the adjustment. Retighten the air shutter screw. Close the oven door and recheck the flame. When all adjustments are made and the results are satisfactory: 1. Replace the orifice fitting cover.

  • Page 11

    Instrucciones de Instalación ¿Preguntas? Llame al 1.800.GE.CARES (800.432.2737) o bien visite nuestra página Web: www.GEAppliances.com ANTES DE EMPEZAR: Lea estas instrucciones y las advertencias completa y cuidadosamente. EN LA MANCOMUNIDAD DE MASSACHUSETTS: • Este producto debe ser instalado por un plomero licenciado o por un técnico de gas.

  • Page 12

    Instrucciones de Instalación PREPARACIÓN PARA LA INSTALACIÓN DEL HORNO LISTA DE HERRAMIENTAS Taladro con Punta de 1/8″ Gafas de seguridad Llave inglesa Regla y vara derecha ajustable Llave inglesa para cañerías Nivel de espíritu de 12″ Soquete hexagonal de 3/16″ Destornillador Phillips No.

  • Page 13

    Instrucciones de Instalación PREPARE LA ABERTURA Espacio del gabinete: 24″ mín. de profundidad 24″ mín. de anchura Abertura: 22 3/16″ de anchura 38″ de altura 3/8″ mín. en ambos lados (Vea Fig. 2) Es buena idea usar un molde para hacer un corte derecho.

  • Page 14

    Instrucciones de Instalación INSTALACIÓN DEL HORNO CONEXIONES ELÉCTRICAS Un abastecimiento y receptáculo eléctrico adecuado debe ser usado para operar las partes eléctricas de su horno. El cordón del horno tiene un enchufe de tres patas y debe ser usado con un receptáculo de tres hoyos que haga tierra adecuadamente con corriente alterna normal de casa de 120 Voltios, 60 Ciclos.

  • Page 15

    Instrucciones de Instalación CONEXIONES DEL GAS (cont.) Coloque el horno en el corte. Nivele el horno: 1. Coloque el nivel de espíritu sobre una de las parrillas del horno. 2. Si el horno no está nivelado, ajuste los niveladores de las patas. 3.

  • Page 16

    Instrucciones de Instalación INSTALACIÓN DEL HORNO CÓMO REVISAR LAS LLAMAS DE LOS QUEMADORES A GAS NATURAL El horno viene ajustado de fábrica para ser usado con gas natural en la mayoría de las áreas. Pero, como el gas en algunas áreas varía, usted debe revisar todos los ajustes que se describen más abajo.

  • Page 17

    Instrucciones de Instalación CÓMO COLOCAR BIEN EL HORNO IMPORTANTE: materiales de empaque y la literature del horno antes de hacer cualquier conexión eléctrica. Usando un barreno de 1/8″, haga hoyos a través de las molduras laterales y en el frente del gabinete.

  • Page 18

    Instrucciones de Instalación CÓMO HACER LA CONVERSIÓN PARA GAS L.P. ADVERTENCIA: a usar gas L.P. (embotellado), todos los ajustes descritos más abajo deben hacer antes de hacer cualquier ajuste a los quemadores o usar el horno. ADVERTENCIA: debe ser hecha por un instalador competente o por el abastecedor de gas de acuerdo con las instrucciones del fabricante y todos los códigos y requerimientos de las autoridades que tienen...

  • Page 19

    Instrucciones de Instalación PARA QUEMADORES PARA HORNEAR Y ASAR Use una llave de 1/2″ o una llave ajustable para hacer girar la tapa del orificio en dirección de L.P., aprox. 1 1/2 vuelta, hasta que quede apretada. L.P. Obturador de Aire NAT.

  • Page 20

    Instrucciones de Instalación CÓMO HACER LA CONVERSIÓN PARA GAS L.P. AJUSTE EL OBTURADOR DE AIRE CONT QUEMADOR PARA HORNEAR Obturador de Aire Tornillo del Obturador de Aire Use un destornillador para soltar el tornillo del obturador. 1. Si las llamas estaban amarillas, abra el obturador de aire más que la posición original.
