Browning Fishing BSL500C Quick Start Manual

BSL500C / BSL750C
Congratulations on your purchase of a Browning Fishing Superlight
spinning reel! This reel is the ultimate tool for any light line shing
situation—Trout-Crappie-Pan sh don't stand a chance. The Superlight
was designed with a lightweight graphite frame and double
anodized-aluminum spool to resist corrosion. The 5-bearing system,
including our Powerlock™ instant anti-reverse, keeps the drive train
moving smoothly. The Superlight has been upgraded to include an EVA
knob for all-day shing comfort.
Reel Specifications
Weight Max Line Capacity
Model Bearings (oz.) Drag (lbs.) mono (lb./yds.) IPT Gear Ratio
BSL500C
5 (4+1) 5.9 8 2/200, 4/120, 6/60 14"
BSL750C 5 (4+1) 6.3 8 4/200, 6/110, 8/85 17"
• 5-Bearing System (4+1)
• Lightweight Graphite Frame
• Anodized Aluminum Spool
• Machined-Aluminum Handle
• EVA Handle Knob
Features and Operations Instructions
Lightweight Graphite Frame
The frame was designed to be lightweight, durable, and corrosion-resistant.
Anodized-Aluminum Spool
The spool has been double-anodized to provide years of corrosion-resistance.
Drag Setting
Your reel is equipped with a drag system to help you ght sh without the risk of
breaking your line. To properly set the drag, you will need a spring scale. Your drag
should be set at 25% of the test rating of your line. Tie a loop in the end of your main
line. Run it through the guides of your rod and attach it to the hook on the scale. Pull
the scale until it registers 25% of the line rating. If you are using 6 lb. test, then you
should set your drag to start slipping at 1.5 lbs.
Powerlock™ Instant Anti-Reverse
This model is equipped with a Powerlock instant anti-reverse system. This is a
special type of bearing that allows the handle to only turn forward. There is no play
in the handle, so you have complete control during the retrieve and no "loose"
feeling, which is important during stop-and-go retrieves.
Machined-Aluminum Handle with EVA Knob
The Superlight reel comes equipped with a machined-cut aluminum handle and
EVA knob. The handle is exceptionally strong and the knob provides all-day
comfort.
Reel Care And Lubrication
®
Your new reel is designed to provide years of dependable service. But like any
other precision machine, periodic cleaning and maintenance is required for
continued peak performance.
Reels made today require both a lightweight oil and grease. Oil and grease should
be used sparingly; too much can have a negative impact on reel performance.
There are lightweight oils and grease made speci cally for shing reels that can be
found at basspro.com.
As a rule of thumb, oils should be used to lubricate any moving part on the reel,
e.g. ball bearings, bushings, handle joints, bail springs, etc. Grease should be used
to lubricate the main drive gear and pinion gear.
We do not recommend using any multipurpose oils. Many of these oils have
properties that will attract dirt and dust to the internal parts. This may cause
excessive wear and reduce the life of the reel.
After each trip, the reel should be checked for dirt or sand. If it has been exposed
to saltwater, the spool should be removed and the entire reel rinsed in freshwater.
Dry with a soft cloth and lubricate the reel as described above.
5.2:1
For professional cleaning and maintenance, send your reels postage prepaid to:
5.2:1
Outdoor World Rod & Reel Repair
2300 E. Turner, Suite M
Spring eld, MO 65803
Phone: (417) 873-5274 Fax: (417) 873-5280
Browning Fishing Reels:
®
Limited Warranty
Bass Pro Shops will repair or replace (at our discretion) any Browning Fishing reel
which proves to be defective in workmanship or materials within one year from the
original date of purchase. You must save your dated sales receipt for warranty
validation. This warranty gives you speci c legal rights, and you may have other
rights which vary from state to state or province to province.
For reels purchased through our catalogs or Bass Pro Shops online:
• For reel replacement only: Return your reel postage prepaid with your dated
sales receipt to the Return Center address listed on your receipt.
• For reel repair only: Return your reel postage prepaid with a copy of your dated
sales receipt as proof of purchase and warranty validation to the Outdoor World
Rod & Reel Repair ® address below.
For reels purchased through Bass Pro Shops retail locations:
• For reel replacement only: Return your reel (postage prepaid if sending
by mail) along with your dated sales receipt to the store from which it was
purchased.
• For reel repair only: Return your reel postage prepaid with a copy of your dated
sales receipt as proof of purchase and warranty validation to the Outdoor World
Rod & Reel Repair address below.
Outdoor World Rod & Reel Repair
2300 E. Turner, Suite M
Springfield, MO 65803
This warranty does not cover lost parts, malfunctions, or damage due to abuse,
accidents, or normal wear. Failure to clean, lubricate and provide reasonable and
necessary maintenance will void the warranty. Repairs needed to your reel due to
abnormal use or modi cation, or after warranty expiration, are available for a
reasonable charge from Outdoor World Rod & Reel Repair, providing the reel is
returned postage paid.
Except to the extent prohibited by applicable law, there are no warranties or
conditions, express or implied, other than those expressly set out herein. Bass Pro
Shops shall not, under any circumstances, be liable for an amount greater than the
actual purchase price of the product nor for any special, incidental, or
consequential damages suffered or incurred in connection with the product and
Bass Pro Shops does not assume, and does not authorize any person to assume
for it, any obligation or liability other than those expressly set out herein.
BP121773
BSL500C / BSL750C
