C 24
User guide
1. Introduction
C24 fittings allow to remotely supply power to 24Vdc luminaries. There are two models depending on
the output power:
· C24-100 (100W)
· C24-300 (300W).
These are intelligent domotic devices which give warnings about possible anomalies both in the centrals
themselves and / or in the lines where the emergency lighting is connected.
It is possible to control the centrals from a PC.
24Vdc permanent outputs available.
3 24 Vdc (50w max.) relay outputs controlled by BUS.
In this gued you will find detailed information about the C24 centrals and its configuration.
2. Technical data
· Voltage: 230 V AC +/- 10%.
· Wire section: 2,5 mm
· Output voltage: 24 V DC +/- 20%.
· Outputs wire section: 2,5 mm
· Working temperature: -5ºC to 25ºC.
· Class: I.
· IP30.
· Outputs: 4.
· Maximum current: 3,5 A on each output.
· Dimensions:
· C24-100: 340 x 330 x 90 mm.
· C24-300: 500 x 400 x 200 mm.
Central
Battery
System
.
