- Page 1 Aquam8012A/Aquam8512A Series Industrial Ethernet Switches Hardware Installation Manual Publication Date: May. 2016 Version: V1.2 No.: 112023041...
- Page 2 Aquam8012A/Aquam8512A Series Industrial Ethernet Switches Hardware Installation Manual Disclaimer: Kyland Technology Co., Ltd. tries to keep the content of this manual as accurate and as updated as possible. This document is not guaranteed to be error-free, and we reserve the right to amend it without notice to users.
- Page 3 Before using the device, read this manual carefully for personal and equipment safety. Please keep the manual for further reference. Kyland is not liable to any personal or equipment damage caused by violation of this notice.
- Page 4 Do not purchase parts from other channels. ● Dispose of the device in accordance with relevant national provisions, preventing environmental pollution. In the following cases, please immediately shut down your power supply and contact your Kyland represen- tative: ● Water gets into the equipment. ●...
-
Page 5: Table Of Contents
Contents 1 Product Overview…………………………………………………… 1 2 Structure and Interface……………………………………………… 2 3 Mounting………………………………………………………………3 3.1 Dimension Drawing……………………………………………3 3.2 Mounting Modes and Steps… … … … … … … … … … … … …4 4 Connection…………………………… … … … … … … … … … … 5 4.1 10/100Base-T(X) Ethernet Port………………………………5 4.1.1 Functions……………………………………………………5 4.1.2 Pin Definitions and Wiring Sequence……………………5... -
Page 7: Product Overview
1 Product Overview Aquam8012A/Aquam8512A includes a series of high-performance industrial Ethernet switches developed by Kyland particularly for rail transportation industry. The series devices are applicable to PIS, CCTV, video monitoring system, train control system, and the industrial field with strict requirements on vibration, shock, and... -
Page 8: Structure And Interface
Table 2 Optional Accessories Model Description Remarks Female cable connector M12-A-4P-F Power port connector with M12, A-Coding, 4 Pin Console/USB port Male cable connector M12-A-4P-M connector with M12, A-Coding, 4 Pin Male cable connector 10/100Base-T(X) port M12-D-4P-M with M12, D-Coding, 4 Pin connector Male cable connector 10/100/1000Base-T(X) -
Page 9: Mounting
(11) 10/100Base-T(X) Ethernet port connection status LED (12) 10/100Base-T(X) Ethernet Port POE LED (13) 10/100/1000Base-T(X) Ethernet port (14) 10/100/1000Base-T(X) Ethernet port connection status LED Note: Non-PoE products do not have PoE indicators. ● For products that support the bypass function, the two gigabit ports ●... -
Page 10: Mounting Modes And Steps
3.2 Mounting Modes and Steps The series devices support panel mounting. Before installation, make sure that the following requirements are met. 1) Environment: temperature (-40°C to 70°C), ambient relative humidity (5% to 95%, non-condensing). 2) Power requirement: The power input is within the voltage range of the switch. 3) Grounding resistance: <5Ω... -
Page 11: Connection
4 Connection 10/100Base-T(X) port connector, 10/100/1000Base-T(X) port connector, console port connector, USB port connector, power port connector, and power port connection cable are all optional (For details, see Table 2 ). That is, these components need to be purchased separately as required. 4.1 10/100Base-T(X) Ethernet Port 4.1.1 Functions Data Transmission... - Page 12 Figure 5 RJ45 Port You can use an M12-M12 or M12-RJ45 cable to connect the port for communication. The preceding figures show the pin numbers of an M12 port and an RJ45 port. For pin definitions, see the following table. Table 3 Pin Definitions of M12/RJ45 Port Wiring Sequence ●...
-
Page 13: 10/100/1000Base-T(X) Ethernet Port
Facing the B Facing the A direction direction Straight-through cable M12 RJ45 Orange and White Green and White Orange Green Cross-over cable Green and White Orange and White Green Orange Figure 6 Connection Using Straight-through/Cross-over Cable 4.2 10/100/1000Base-T(X) Ethernet Port 10/100/1000Base-T(X) Ethernet port is equipped with M12 connector, which is dustproof, waterproof, and anti-vibration. - Page 14 Figure 8 RJ45 Port You can use an M12-M12 or M12-RJ45 cable to connect the port for communi- cation. The preceding figures show the pin numbers of an M12 port and an RJ45 port. For pin definitions, see the following table. Table 4 Pin Definitions of M12/RJ45 Port...
- Page 15 Wiring Sequence ● Facing the B Facing the A direction direction Straight-through cable M12 RJ45 M12 RJ45 Cross-over cable Figure 9 Connection Using Straight-through/Cross-over Cable Note: The color of the cable for RJ45 connector meets the 568B standard: 1- orange and white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8-brown.
-
Page 16: Console Port
4.3 Console Port There is a console port on the front panel. The port is equipped with M12 connector. Connect the console port of the switch to the 9-pin serial port of a PC with an M12-DB9 console cable. You can configure, maintain, and manage the switch by running Hyper Terminal in Windows OS of a computer. -
Page 17: Grounding
4.4 Grounding Grounding protects the device from lightning and interference. Therefore, you must ground the device properly.You need to ground the device before it is powered on and disconnect the grounding cable after the device is powered off. There is a grounding screw (see Figure 1) on the front panel of the device. The screw is for chassis grounding. -
Page 18: Bypass Port
Table 6 Pin Definitions of Power Port Wiring and Mounting ● Step 1: Ground the device properly according to section 4.4. Step 2: Insert one end of the power cable into the M12 connector firmly. Step 3: Insert the M12 connector with the connected cable into the power port on the device. -
Page 19: Leds
Port11 Port12 Switch A Aquam8512A Switch B Figure 13 Bypass 5 LEDs Table 7 Front Panel LEDs The POE port provides power supply normally Ethernet port The POE port provides power supply abnormally POE LED-POE The POE port provides no power supply... -
Page 20: Switch Access
6 Switch Access You can access the switch in any of the following ways. 6.1 Access through Console Port Step 1: Connect the console port of the switch to the 9-pin serial port of a PC with the M12-DB9 console cable. Step 2: Open Hyper Terminal in Windows OS. - Page 21 Step 4: Connect the communication port in use, as shown in the following figure. Figure 15 Selecting a Serial Port Note: To confirm the communication port in use, right-click [My Computer] and select [Property]. Click [Hardware] → [Device Manager] → [Port] to view the communication port.
- Page 22 Step 5: Set port parameters (Bits per second: 115200, Data bits: 8, Parity: None, Stop bits: 1 and Flow control: None), as shown in the following figure. Figure 16 Setting Port Parameters Step 6: Click OK to enter the switch CLI. Then you can run the commands in Table 8 and Table 9 to perform operations.
-
Page 23: Access Through Telnet
Step 2: On the Windows desktop, click Start and Run. The Run Dialog box is displayed. Enter "telnet IP-address”. For example, if the IP address of the switch is 192.168.0.2 (default IP address of a Kyland switch), enter "telnet 192.168.0.2" in the dialog box. -
Page 24: Basic Features And Specifications
7 Basic Features and Specifications Meeting EN50155 H6 (72/96/110VDC) 72-110VDC 24-110VDC Aquam8012A without POE: 13W (MAX) Aquam8012A with POE: 101W (MAX) Aquam8512A without POE: 18W (MAX) Aquam8512A wuth POE: 108W (MAX) Aquam8012A without POE: MAX 0.45A @ 24VDC MAX 0.22A @ 48VDC MAX 0.14A @ 72VDC MAX 0.10A @ 110VDC Aquam8012A with POE: MAX 4.2A @ 24VDC... - Page 28 FAX: +86-10-88796678 Website: http://www.kyland.com Email: support@kyland.com For more information about KYLAND products, please visit our website: http://www.kyland.com...
