OPERATOR MANUAL OSD8816B SERIES DIGITAL VIDEO AND DATA FIBER OPTIC TRANSMISSION SYSTEM... -
Page 3: Table Of Contents
OPTICAL SYSTEMS DESIGN INDEX 1 TECHNICAL SUMMARY ......................4 BRIEF DESCRIPTION ......................4 1.1.1 OVERVIEW ......................... 4 1.1.2 APPLICATIONS ........................4 1.1.3 FEATURES AND BENEFITS ..................... 4 TYPICAL CONFIGURATION ....................5 PRODUCTS AND OPTIONS ....................6 TECHNICAL SPECIFICATIONS ................... 7 PIN ASSIGNMENTS ....................... -
Page 4: Technical Summary
1.1.1 OVERVIEW The OSD8816B series is a high-quality fiber optic digital video and data transmission system. The system consists of the OSD8816BT and the OSD8816BR, which are designed to be used as a pair, and provide one-way transmission of PAL, NTSC or SECAM video, plus full-duplex transmission of one data channel. -
Page 5: Typical Configuration
OPTICAL SYSTEMS DESIGN TYPICAL CONFIGURATION Figure 1 below indicates the typical set-up for an OSD8816B system. FIGURE 1: TYPICAL CONFIGURATIONS The OSD8816BT and OSD8816BR pair can provide one forward video transmission and full duplex data transmission between camera (transmitter) and monitoring site (receiver) or one way data transmission from the monitoring site (receiver) to the camera (transmitter) only. -
Page 6: Products And Options
OPTICAL SYSTEMS DESIGN PRODUCTS AND OPTIONS There are various options available for the OSD8816B as identified in Table 1 below: OSD8816B (example only) TABLE 1: PRODUCTS AND OPTIONS ITEM DESCRIPTION Transmitter ITEM DESCRIPTION Card version (3RU high chassis mount for OSD370 or OSD350) -
Page 7: Technical Specifications
OPTICAL SYSTEMS DESIGN TECHNICAL SPECIFICATIONS TABLE 2: TECHNICAL SPECIFICATIONS SPECIFICATION PERFORMANCE 75Ω composite Video Input/Output Impedance Video Input/Output Levels 1Vpp nominal Video Connectors Video Bandwidth 5Hz to 10MHz > 67dB for 10-bit operation Signal to Noise Ratio (Weighted) > 64dB for 9-bit operation <0.7% Differential Phase (DP) -
Page 8: Pin Assignments
OPTICAL SYSTEMS DESIGN PIN ASSIGNMENTS Pin assignments for the “Data Input/Output” 8 way terminal block connector (Figure 2) is shown in Table 3 below. TABLE 3: PIN ASSIGNMENT FUNCTION FUNCTION Data Input + Data Output − / Data Input –... -
Page 9: Data Mode Switch Settings
OPTICAL SYSTEMS DESIGN 8-Way Data Connector Connector Power Connector See section 2.2.3 FIGURE 2: REAR PANEL CONNECTORS DATA MODE SWITCH SETTINGS The 3-way data control switch is located at the front of OSD8816B modem. Switches SW1, SW2 and SW3 are used for setting the Data Mode Options. -
Page 10: Installation And Operation
OPTICAL SYSTEMS DESIGN 2 INSTALLATION AND OPERATION INTRODUCTION This section outlines the methods required to install and operate the OSD8816BT and OSD8816BR successfully. It should be studied carefully if damage to the equipment or poor results are to be avoided. -
Page 11: Drawings And Dimensions
OPTICAL SYSTEMS DESIGN 2.2.2 DRAWINGS AND DIMENSIONS The OSD8816BTC and OSD8816BRC are designed to be mounted on an even surface and to be secured by means of M4 or smaller screws. The OSD8816BT and OSD8816BR card versions are designed to be inserted into a chassis and secured by means of captivated screws. -
Page 12: Power Supply Connections
OPTICAL SYSTEMS DESIGN 2.2.3 POWER SUPPLY CONNECTIONS The OSD8816B card version is powered from the OSD370N or OSD350N chassis. DC power in the OSD881B6 card version is connected via a DB9 connector. The card version of the OSD8816BT and OSD8816BR should be fixed into the chassis using the captivated screws. Either card can be plugged in or out of the chassis with power on or off. -
Page 13: Other Connections
OPTICAL SYSTEMS DESIGN 2.2.4 OTHER CONNECTIONS The video-input signal (eg. from camera) is connected to the video input BNC connector on the OSD8816BT. The video output signal (eg. to monitor) is connected from the video output BNC connector on the OSD8816BR. -
Page 14: Osd8816B Operation
OPTICAL SYSTEMS DESIGN OSD8816B OPERATION 2.3.1 OSD8816BT AND OSD8816BR OPERATION When using the OSD8816B for the first time, check that the unit is in good condition with no visible damage. If a card version is used, insert it in an appropriate slot on the OSD370 or OSD350 chassis and check that the indicators illuminate accordingly on power up (see Table 5). -
Page 15: Osd8816Bt And Osd8816Br Indicators
OPTICAL SYSTEMS DESIGN 2.3.2 OSD8816BT AND OSD8816BR INDICATORS Video Present Indicators Link OK FIGURE 7: LED INDICATORS TABLE 7: INDICATOR FUNCTION INDICATOR PARAMETER COLOUR FUNCTION No video signal present Video Input Status VIDEO PRESENT Amber Video signal present No optical signal received... -
Page 16: Maintenance
OPTICAL SYSTEMS DESIGN 3 MAINTENANCE INTRODUCTION The following section outlines the fault-finding procedure for the OSD8816BT and OSD8816BR modems. Please take note of the following: ▲ Personnel without appropriate training should not attempt any maintenance except that outlined below. If further maintenance is attempted you are warned that every care should be taken to ensure that ▲... -
Page 17: Warranty
For warranty period, please call your local OSD distributor. REPAIRS Optical Systems Design reserves the right to repair or replace faulty modules/units. Please obtain a “Return Material Authorisation” (RMA) form and number before returning goods. Goods must be returned in adequate packing material to Optical Systems Design, Warriewood or its nominated authorised representative, for all repairs. - Page 20 OPTIC L Optical Systems Design Pty. Ltd. 7/1 Vuko Pl. Warriewood 2102 SYSTEMS P.O. Box 891 Mona Vale N.S.W. Australia 2103 Telephone: +61 2 9913 8540 DESIGN Facsimile: +61 2 9913 8735 Email: sales@osd.com.au Web Site: www.osd.com.au PTY LTD A.B.N. 83 003 020 504...
