Si001168

Step

4

Remove the discharge

grille.

Remove the nut of the

5

outdoor fan.

Remove the 2 screws

6

on the partition plate

(1).

Removal Procedure

Procedure

Outdoor fan

Partition plate (1)

Removal of Outer Panels

(R6204)

Nut size : M8

(R16878)

(R16879)

Points

13 mm

(R12301)
