Z3 Dual Tone Operation (Alt Tone); Universal Dual Tone (Non-Z3 Systems); Electronic Air Horn Configuration - Code 3 Banshee Installation & Operation Manual

Z3 Dual Tone Operation (ALT TONE)

To configure the Dual Tone for the Z3 Control Head ALT TONE button, set the DIP switches according to Table 5 (reference Figure 4).
Table 5: Z3 Dual Tone ALT TONE Configuration
Switch Position 2
Down
Up
Down
Up
Down
Up
Down
Up
*Factory Default Setting.
Universal Dual Tone (non-Z3 Systems) - The Dual Tone feature can be configured to operate with most industry standard siren systems, turning
a single tone siren system into a Dual Tone system. The Dual Tone feature will only operate when the primary siren system is generating a tone.
When there is a signal from a primary siren and the Dual Tone input is activated, the Banshee can generate one of eight tones.
To configure the Dual Tone, set the DIP switches according to Table 6 (reference Figure 5).
Switch Position 2
Down
Up
Down
Up
Down
Up
Down
Up
*Factory Default Setting.

Electronic Air Horn Configuration

The Electronic Air Horn can be used with a primary siren or as an independent Electronic Air Horn. The Banshee does not require a signal from a
primary siren to activate the Electronic Air Horn feature. The Banshee will generate the configured tone as long as the Air Horn input is activated.
There are two tones that can be configured to be used with the Air Horn input:
- Electronic Air Horn.
- Yelp Stop.
To configure the Electronic Air Horn, set the DIP switch according to Table 7 (reference Figure 6).
Table 7: Electronic Air Horn Tone Configuration
Switch Position 8
Down
Up
*Factory Default Setting.
Note: If the Electronic Air Horn is used in a vehicle that must be California Title 13 compliant, a relay (user supplied) must be installed so that the
Air Horn input is disabled in accordance with the regulation.
Switch Position 3 Switch Position 4
Down Down
Down Down
Up Down
Up Down
Down Up
Down Up
Up Up
Up Up
Table 6: Universal Dual Tone Configuration
Switch Position 3 Switch Position 4
Down Down
Down Down
Up Down
Up Down
Down Up
Down Up
Up Up
Up Up
Configuration
*Electronic Air Horn
Yelp Stop
Configuration
Wail
Yelp
Hyper-Yelp 1
Hyper-Yelp 2
*Hi-Lo 1
Hi-Lo 2
Hyper-Lo 1
Hyper-Lo 2
Configuration
*Wail
Yelp
Hyper-Yelp 1
Hyper-Yelp 2
Hi-Lo 1
Hi-Lo 2
Hyper-Lo 1
Hyper-Lo 2
