Siren Specifications - Code 3 Banshee Installation & Operation Manual

Specifications
Input Voltage
Operating Current 100W: 8 Amps @ 13.6V with 11-ohm load (100 Watt Speaker)
Standby Current
Cycle Rate
Voltage Output
Weight:
Size:
Temperature:
Banshee Siren System - Parts List
Ref No. Description
1 Banshee Amplifier
2 Power Harness
3 Input/Output Harness
4 CAT5 Cable, 10FT
5 Install Manual
10 to 16 VDC, negative ground (earth)
Note: Operation of 12V units above 15 VDC for an extended period of time may result in speaker damage.
200W: 14 Amps @ 13.6V with 5.5-ohm load (2-100 Watt Speakers)
Ignition On < 10mA (no other inputs activated)
Ignition Off < 1mA
Wail - 12 cycles/minute (675 to 1700Hz)
Yelp - 194 cycles/minute (675 to 1700Hz)
Hyper-Yelp 1 - 390 cycles/minute (675 to 1700Hz)
Hyper-Yelp 2 - 260 cycles/minute (675 to 1700Hz)
Hi-Lo 1 - 48 cycles/minute (Alternating 833Hz and 1250Hz)
Hi-Lo 2 - 40 cycles/minute (Alternating 714Hz and 1000Hz)
Hyper-Lo 1 - 96 cycles/minute (Alternating 833Hz and 1250Hz)
Hyper-Lo 2 - 80 cycles/minute (Alternating 714Hz and 1000Hz)
CommandAlert - 118 cycles/minute (476 to 1000Hz)
Low Frequency Yelp - 157 cycles/minute (303 to 556Hz)
Low Frequency Wail - 12 cycles/minute (303 to 476Hz)
Note: The Synchronized 1/2 Frequency tone will operate at 1/2 of the frequency of the primary siren. It will clamp the
minimum frequency at 303Hz if the primary siren frequency is too low. When used with most industry standard sirens,
the Synchronized 1/2 Frequency should operate at approximately 350 to 850Hz.
~ 66 Vpp
3.2 lbs (1.4 Kg)
8.5"L x 5.7"W x 2.8"H
-22F thru +149F (-30C thru +65C) SAE Equipment Type EVS1
Part No.
T54124
T56637
T16281
T57555
T16282
10
Qty.
1
1
1
1
1
