- Page 1 Service Guide SW-Flat 2.1 500 SERVICE GUIDE SYSTEMS CORP. SW-Flat 2.1 500 Version : 1.0 Version : 1.0 Page 1 of 16...
- Page 2 Service Guide SW-Flat 2.1 500 Revision History Version Date Change 07/27/2004 Version : 1.0 Page 2 of 16...
-
Page 3: Table Of Contents
Service Guide SW-Flat 2.1 500 Table of Contents Revision History … … … … … … … … … … … … … … … … … … … … … … … … … … .2 Table of Contents … … … … … … … … … … … … … … … … … … … … … … … … … … 3 Getting Started …... -
Page 4: Getting Started
Service Guide SW-Flat 2.1 500 Getting Started Conventions Used in this Guide Pay Special Attention : Instructions that are important to remember and may prevent mistakes . Caution : Information that, if not followed, may result in damage to the product . -
Page 5: Chapter 1. How To Handle Defective Returns
Service Guide SW-Flat 2.1 500 Chapter 1. How to Handle Defective Returns 1.1 Overview Receiving Defective speakers form Customers Verifying problems & Proceeding necessary tests Function NG Analyzing possible malfunction causes Deciding & proceeding the Function NG rectification methods Function OK... -
Page 6: Problems
Service Guide SW-Flat 2.1 500 1.2 Problems Item Problem Description 1.2.1 One or more channels no sound 1.2.2 Volume , Bass no function 1.2.3 Power LED (indicator) no light 1.2.4 Head-sets no sound Version : 1.0 Page 6 of 16... - Page 7 Service Guide SW-Flat 2.1 500 Attention Please follow the numbered sequence marked within parenthesis given in individual Flow chat, in that this is the best-recommended sequence to rectify the problems . 1.2.1 One or more channels no sound One or more channels no sound...
- Page 8 Service Guide SW-Flat 2.1 500 1.2.2 Volume , Bass no function Volume , Bass no function Problem Analyzer and Broken or short circuit Defective VR1 , VR2 Identify the Causes Check and Replace defective Solutions Check solder points on PCB components 1.2.3...
- Page 9 Service Guide SW-Flat 2.1 500 1.2.4 Head-sets no sound Head-sets no sound Problem Analyzer and Broken or short circuit Defective T1 , R11 , R12 Identify the Causes Check and Replace defective Solutions Check solder points on PCB components Version : 1.0...
-
Page 10: Chapter 2. Specifications
Service Guide SW-Flat 2.1 500 Chapter 2. Specifications ： SATELLITE (AT 1KHz) NO. Description Unit Specifications ≧ 2.3 Out Power at THD 10% 350 ± 50 Sensitivity Freq. Response (Ref:-3dB) Hz 400Hz ~ 20KHz dB ≧ -30 Separation dB ≧ -45 S/N ratio Hum &... -
Page 11: Chapter 3. Block Diagram
Service Guide SW-Flat 2.1 500 Chapter 3. Block Diagram Audio In R.CH Speaker Power Volume Control Amplifier L.CH Speaker AC IN Transformer Power Woof. Volume Amplifier Woof.CH Speaker Version : 1.0 Page 11 of 16... -
Page 12: Chapter 4. Exploded View
Service Guide SW-Flat 2.1 500 Chapter 4. Exploded View Host ( Woofer ) Version : 1.0 Page 12 of 16... - Page 13 Service Guide SW-Flat 2.1 500 Satellite Version : 1.0 Page 13 of 16...
-
Page 14: Chapter 5. Part List
Service Guide SW-Flat 2.1 500 Chapter 5. Part List DESCRIPTION Unit Part No. SW-Flat2.1 500/BODY/SATELLITE 1-101-01 SPEAKER UNIT DBA288 1-100-01 RUBBER, SW-FLAT2.1 500/SATELLITE 1-100-09 SW-FLAT2.1 500/BODY/HOST 1-101-02 SPEAKER UNIT RBA398 1-100-02 PCBA, SW-FLAT2.1 500 1-101-03 IC, TEA2025B/TEA2025 1-100-03/04 IC, YG4558/MC4558, SW-FLAT2.1 500... -
Page 15: Chapter 6. Schematic Diagram
Service Guide SW-Flat 2.1 500 Chapter 6. Schematic Diagram Version : 1.0 Page 15 of 16... -
Page 16: Chapter 7. Important Notes
Service Guide SW-Flat 2.1 500 Chapter 7. Important Notes 7.1 Packing Requirement for Sending the PCB Assembly by Post PCB assembly is a kind of sophisticated electronic circuit board. Well packing will be required when sending them by post. * Some sophisticated IC components are mounted on the PCB assembly, hence it is necessary to pack each PCB assembly with a separate static protecting bag, in order to avoid static electricity.
