Questions? Contact us! / Des questions? Contactez-nous!
Monday to Friday, from 8:30 a.m. to 12 p.m., 1 p.m. to 4:30 p.m. (Eastern standard time).
Keep handy your proof of purchase, the Amisco product number and the product labels.
Du lundi au vendredi, de 8h30 à 12h00, 13h00 à 16h30 (heure de l'Est).
Ayez en main votre preuve d'achat, le numéro de produit Amisco et les étiquettes du produit.
1 800 361-6360
2 PEOPLE / 2 PERSONNES
PARTS LIST / LISTE DES PIÈCES
ITEM
DESCRIPTION
Table base
1
Base de table
Brace
2
Tige renfort
Hardware
3
Sac de quincaillerie
The model illustrated may differ from the model bought. The assembly method remains the same.
Le modèle illustré peut être différent du modèle acheté. La méthode d'assemblage demeure la même.
In order to protect certain floor coverings, we suggest you to use self-adhesive felts under legs.
Afin de protéger certains revêtement de plancher, nous suggérons d'utiliser des feutres autocollants sous les pattes.
1) Put on a large blanket to protect the finished surface.
Placer sur une grande couverture pour protéger le côté fini.
2) Center the table base on wood top and screw. (do not overtight).
Centrer la base de table sur le dessus de bois et visser. (ne pas trop serrer)
3) Screw on glides.
Visser les glisseurs.
A
12 or /ou 16 X
4 X
TABLE ASSEMBLY
ASSEMBLAGE DE LA TABLE
WWW.AMISCO.COM
You will need / Vous aurez besoin
HARDWARE LIST / LISTE DE QUINCAILLERIE
QTY
QTY
ITEM
Others /
Autres
50503
A
1
2
B
0
0/4
C
1
1
D
(TOP NOT INCLUDED)
(DESSUS NON-INCLUS)
- A phillips screwdriver or wireless phillips screwdriver.
- A measuring tape or ruler.
- Un tournevis cruciforme ou un tournevis cruciforme sans fil.
- Un ruban à mesurer ou règle.
DESCRIPTION
Wood screw
Vis à bois
Self-drilling screw
Vis auto-perçante
Wood screw
Vis à bois
Glide
Glisseur
1
M656480055
Revision: 08,
24-09-2018 G.L.
Problem ? / Problème ?
Let us help you,
PLEASE DO NOT RETURN
YOUR PRODUCT.
Laissez-nous vous aider,
S.V.P. NE RETOURNEZ PAS
VOTRE PRODUIT.
QTY
QTY
Others /
Autres
50503
3/4" # 10
12/16
16
1/2" # 8
0
4
5/8" # 8
0
4
4
4
D
1
