M656480155 / Revision: 3, 25-08-2016 G.L.
ZOOM TABLE BASE (top not included)
BASE DE TABLE ZOOM (dessus non-inclus)
50522
IMPORTANT
Dealer or installer: Leave all documents to the consumer.
Détaillant ou installateur: Laissez tous les documents au consommateur.
Consumer: Keep this document and the warranty sheet with your proof of purchase for reference.
Consommateur: Conservez ce document et la feuille de garantie avec votre preuve d'achat pour référence.
Do not
contact or return
your product to
the store
Contact us within 30 days from your
purchase date. Monday to Friday, from
8:30 a.m. to 12 p.m., 1 p.m. to 4:30 p.m.
(Eastern standard time). Keep handy
your proof of purchase and the Amisco
product number when calling.
PARTS LIST / LISTE DES PIÈCES
DESCRIPTION
ITEM
1
Base frame
Cadre de la base
2
Leg
Patte
3
Hardware bag
Sac de quincaillerie
TWO (2) PEOPLE ARE REQUIRED TO ASSEM-
BLE THIS PRODUCT.

LIST OF TOOLS REQUIRED :

- A phillips screwdriver.
- An allen key 5/32" (included).
- A 7/16" wrench.
IMPORTANT: In order to prevent any damage to
this product, DO NOT USE ANY POWER TOOL to
assemble it.Assemble this product by hand.
1) Insert glides E under legs 2 . In order to protect certain floor coverings, we
suggest you to use self-adhesive felts under legs.
Insérer les glisseurs E sous les pattes 2 . Afin de protéger certains revêtement
de plancher, nous suggérons d'utiliser des feutres autocollants sous les pattes.
Thank you for choosing an Amisco product
Merci d'avoir choisi un produit Amisco
Problems or information?
www.amisco.com
1 800 361-6360
Problèmes ou information?
Amisco product number/Numéro du produit Amisco
QTY
ITEM
A
1
2
B
1
C
D
E
HARDWARE LIST / LISTE DE LA QUINCAILLERIE
DEUX (2) PERSONNES SONT REQUISES
POUR ASSEMBLER CE PRODUIT.
LISTE DES OUTILS NÉCESSAIRES :
- Un tournevis étoile.
- Une clé allen 5/32" (incluse).
- Une clé 7/16".
IMPORTANT: Afin de prévenir tout dommage à ce produit,
NE PAS UTILISER D' OUTILS ÉLECTRIQUES pour son
assemblage. Assembler ce produit manuellement.
Ne contactez
pas le magasin,
ne retournez pas
votre produit
Contactez-nous dans les 30 jours suivant
votre achat. Du lundi au vendredi, de 8h30
à 12h00, 13h00 à 16h30 (heure de l'Est). Ayez
sous la main votre preuve d'achat et le nu-
méro de produit Amisco au moment d'ap-
peler.
DESCRIPTION
Bolt
40 MM X 1/4-20NC
Boulon
Bolt
7/8" X 1/4-20NC
Boulon
Wood screw
3/4" X #10
Vis à bois
Acorn nut
1/4-20NC
Écrou acorn
Glide
Glisseur
2
QTY
8
4
32
4
4
E
1
