GE Monogram ZBD6900PII Owner's Manual page 15

Lower Rack
Remove the
Upper Rack
The lower rack is best used for plates, saucers and
cookware. Large items such as broiler pans and
baking racks should go along the left-hand side.
Load platters, pots and bowls along the sides, in
corners or in the back. The soiled side of items
should face the center of the rack, or they can be
placed soil side down. If necessary, oversized
glasses and mugs can be placed in the lower rack
to maximize loading flexibility.
Your new dishwasher has the capability to wash
extra large items in the lower rack. This is
accomplished by removing the upper rack and
installing a nozzle over the port that normally
supplies water to the upper rack. The nozzle is not
included with your dishwasher, but is available for
purchase from GE. Call GE at 1.800.626.2002 or go
to the GE website ge.com and request Nozzle Spray
Asm, part number WD12X10134.
Shower Nozzle Service Part Number WD12X10134
Customers in Canada can order on-line at
geappliances.ca 24 hours every day, or by phone
at 1.800.661.1616 during normal business hours.
To remove the upper rack, push thumb tab out and
remove the front end caps on each side of the rail.
Push thumb tab
Remove end cap
Loading the Racks
Dishwasher
Also, be careful not to let a portion of an item such
as a pot or dish handle extend through the bottom
rack. This could block the wash arm and cause poor
washing results.
Fold-down tines (on some models) provide flexibility
for extra-large and hard-to-fit items. The tines may
be left in the up position or folded down to customize
the lower rack.
Be sure tall tines in the lower rack do not block the
spray arm above them. Check for this by spinning
the arm when both racks are pushed all the way in.
Pull the rack straight out and off the rails.
Replace the end caps, then push the rails all the
way back into the dishwasher. Slide the shower
nozzle attachment over the spout.
Then fill the lower rack and begin your cycle.
NOTE: Nozzle must be in place with upper rack
removed. If not installed properly, poor wash
performance and noise will result.
NOTE: Don't forget to remove the shower nozzle
attachment before you replace the upper rack.
Shower nozzle
attachment
15
