5391015COM
NIGHTSTAND
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
B345391015COM0
Tough
Advertisement
Related Manuals for Novogratz 5391015COM
Summary of Contents for Novogratz 5391015COM
- Page 1 5391015COM NIGHTSTAND B345391015COM0 Date of Purchase ___ / ___ / ___ Lot Number: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Do Not Return This Product! Contact our customer service team for help first.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 1 HOUR... -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. -
Page 4: Board Identification
Board Identification Not actual size 35391015030 Right Panel Left Panel 35391015010 35391015020 Drawer Front Bottom 35391015050 35391015040 SIDE BACK Drawer Bottom Drawer Back Drawer Side (2) 39991340042110D 39991167041140B 39991167346200C ameriwoodhome.com... - Page 5 Board Identification Not actual size This piece is paperboard construction. It is not made from wood, but is required for the assembly of your unit. Back Panel K53911510 SIDE BACK SIDE ameriwoodhome.com...
-
Page 6: Part List
Part List Actual Size (x4) #A23030 (x4) (x4) (x4) (x1) confirmat screw #A21660 #A22620 #A22610 #A17400 wood dowel cam lock cam bolt 7/8" bolt (x10) (x8) (x12) (x4) (x20) #A11080 #A12120 #A15600 #A21970 #A21110 7/16" flat head 7/16" pan head drive fastener euro screws nail... - Page 7 STEP 1 Quick Assembly (x2) (x2) (x3) #A22620 #A21660 #A11080 Proper orientation of CAM LOCK Left Cabinet Member (x1) #A56770 Marked with a "L". ameriwoodhome.com...
- Page 8 STEP 2 Quick Assembly (x2) (x2) (x3) Proper orientation of CAM LOCK #A22620 #A21660 #A11080 Right Cabinet Member (x1) #A56770 Marked with a "R". ameriwoodhome.com...
- Page 9 STEP 3 (x4) #A22610 ameriwoodhome.com...
- Page 10 STEP 4 (x4) #A23030 unfinished surface ameriwoodhome.com...
- Page 11 STEP 5 ameriwoodhome.com...
- Page 12 STEP 6 (x12) (x4) #A15600 #A44610 ameriwoodhome.com...
- Page 13 STEP 7 IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY. (x20) #A21110 With the help of another person, turn the unit over as shown. Position the back panel (I) as shown. Flush the bottom edge of the back panel with the edge of the bottom (D).
- Page 14 STEP 8 (x4) #A12120 (x2) #A54520 SIDE SIDE Fasten the brackets to the opposite surface of the small metal slide holes. ameriwoodhome.com...
- Page 15 STEP 9 (x4) #A12120 Attach the drawer sides to the Drawer Front (E) with screws (7) as shown. Be sure the groove in the drawer sides are centered with the groove in the drawer front. SIDE SIDE ameriwoodhome.com...
- Page 16 STEP 10 SIDE unfinished surface SIDE ameriwoodhome.com...
- Page 17 STEP 11 (x4) #A21970 Unfinished Surface BACK ameriwoodhome.com...
- Page 18 STEP 12 Left Drawer Member (x4) #A11080 Right Drawer Member (x1) #A56770 Marked with a "L". Marked with a "R". ameriwoodhome.com...
- Page 19 STEP 13 (x1) (x1) #A17400 #A51975 ameriwoodhome.com...
- Page 20 STEP 14 Install the drawer as shown. Note: The drawer bracket holes are slotted. Drawer fronts can be adjusted by loosening screws, making needed adjustments and retightening screws. roller cabinet member drawer runner roller ameriwoodhome.com...
- Page 21 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 40 lbs 15 lbs 18.1 kg 6.8 kg 40 lbs 18.1 kg Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is not approved for use with a television.
- Page 22 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit ameriwoodhome.com Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You"...
- Page 23 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 24 Español Página 13 Con la ayuda de otra persona, voltee la unidad como se muestra. Coloque el panel posterior (I) como se muestra. Enjuague el borde inferior del panel posterior con el borde de la parte inferior (D). Asegúrate de que la unidad sea cuadrada.
- Page 25 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) du Lundi au Vendredi de 9h à...
- Page 26 Français Page 13 Avec l'aide d'une autre personne, retournez l'appareil comme indiqué. Positionnez le panneau arrière (I) comme indiqué. Rincez le bord inférieur du panneau arrière avec le bord du fond (D). Assurez-vous que l'unité est carrée. La distance du coin doit être égale à celle montrée. Fixez le panneau arrière en clouant directement sur les bords arrière comme indiqué.
