- Page 2 THANK YOU Thank you for purchasing your Ashdown Engineering Amplifier and welcome to the family! We really think you’ve made the right choice and know that this amplifier will give you years of great tone and service. It is a machine though and needs to be looked after, please read...
- Page 3 USER GUIDE BASS EXCHANGE...
- Page 4 BASS EXCHANGE USER GUIDE The pedal is provided with the following inputs and outputs: INPUT 1 is the main master input INPUT 2 is a secondary input OUTPUT 1 is the master output for connection to the following equipment ( ie an amplifier) OUTPUT 2 is a secondary output, this is isolated for connection to a second amplifier, or by depressing the “Bal/Norm switch can be turned...
- Page 5 In Position 1+2 the two inputs are routed to BOTH outputs and in 1 or 2 position. Channel 1 in is routed to Output 1 and Channel 2 is routed to output 2 Using the Bass Exchange pedal. 1/ 2 Instruments, 1 Amplifier Connect instruments to Inputs 1 and 2...
- Page 6 BASS EXCHANGE USER GUIDE 1/ 2 Instruments, 2 Amplifiers Connect instruments to Inputs 1 and 2 Function switch OUT Select Mode OUT (1or2) Amplifier connected to Output 1 Second amplifier connected to Output 2 BAL/Norm switch out Using the footswitch select the instrument to be played, the respective...
- Page 7 BASS EXCHANGE USER GUIDE Boost pedal Connect instrument to Inputs 1 ( I this case the Input 1 is also routed through input 2 ) Function switch OUT Select Mode In (1+2) Amplifier connected to Output 1 The second output can be used to drive a second amplifier or used as a Using the footswitch select the instrument channel to be played, the respective meter will illuminate adjust the level set the level LOW.
