FRONT PANEL
1
1.
USB 2.0 for media, firmware update and factory restore
2. Reset button. Press and release to reset. Press and hold 10 seconds to factory restore.
3. Status LEDs. Rx: receiving stream and/or decoding. SF: screen format. Tx: transmitting a stream or
writing to file. WF: WiFi. LTE: cellular. DC: input voltage active, flash indicates system is operational.
4. 12 Volt DC input.
5. microUSB for terminal. Not for users.
6. Monitor: audio and video jack.
BACK PANEL
1
1.
HDMI 1.4b output.
2. 3G SDI output.
3. Gigabit Ethernet port 1. Default avahi named address. [serial number].local/ Default is DHCP.
4. Gigabit Ethernet port 2. Default is 192.168.2.7.
5. USB 3.0 for media, firmware update and factory restore.
CONNECTING TO THE MD9200-DEC
The MD9200-DEC uses a modern HTML5-embedded Web server for user configuration. Users can connect to the device via Gigabit Ethernet (GigE) port 1 or
GigE port 2. GigE port 1 is factory defaulted to DHCP and GigE port 2 is factory defaulted to 192.168.2.7.
UPGRADING FIRMWARE FROM THE WEB UI
1.
Log into the MD9200-DEC web GUI and navigate to the HOST Tab.
2.
Download the firmware to a disk and folder on your Windows/MAC/Linux computer.
3.
Choose File (firmware) from your computer's disk and folder.
4.
Click "Upload" button to upload the firmware from your computer to the MD9200-DEC.
5.
Count down number in "OK" button indicates how long until update automatically continues. Click "OK" to immediately start update.
6.
"Update has begun" prompt. Select "OK" close the window.
Future versions may eliminate blinking. Not indicative of system functionality.
1
10 Newton Place
Hauppauge, NY 11788
1-877-685-8439 / +1-516-671-7278
sales@multidyne.com
www.multidyne.com
2
3
4
.
1
2
3
Update Firmware
© 2018 MultiDyne
© 08/2017 MultiDyne
Stand-Alone OTT Streaming Media Decoder
5
6
4
5
Specifications subject to change without notice
Specifications subject to change without notice
MD9200-DEC
Quick Start Sheet
Web UI
Value
Username
9200
Password
DEC
Gigabit Ethernet Port
Configuration
GigE 1
GigE 2
192.168.2.7
DHCP
© 2019 MultiDyne
Made in USA
Made in USA
Advertisement
Table of Contents
Related Manuals for MultiDyne MD9200-DEC
Summary of Contents for MultiDyne MD9200-DEC
- Page 1 CONNECTING TO THE MD9200-DEC The MD9200-DEC uses a modern HTML5-embedded Web server for user configuration. Users can connect to the device via Gigabit Ethernet (GigE) port 1 or GigE port 2. GigE port 1 is factory defaulted to DHCP and GigE port 2 is factory defaulted to 192.168.2.7.
- Page 2 UPLOADING NEW FIRMWARE FROM A USB DISK The MD9200-DEC supports USB2 and USB3 media devices. To upload the new firmware from a USB media device (thumb-drive), follow the steps below. Download the firmware to a disk and folder on your computer.
