INSTRUCTION MANUAL
HD3000 Gen2 Series
SERIAL DIGITAL VIDEO
FIBER OPTIC TRANSPORT and DISTRIBUTION
SYSTEM FOR HDTV and SDTV
191 FOREST AVENUE
LOCUST VALLEY, NY 11560-2132 USA
(800)-488-8378 / (516)-671-7278 FAX (516)-671-3362
sales@multidyne.com
www.multidyne.com
REV C, Feb 24, 2015
Advertisement
Related Manuals for MultiDyne HD-3000 Series
Summary of Contents for MultiDyne HD-3000 Series
- Page 1 INSTRUCTION MANUAL HD3000 Gen2 Series SERIAL DIGITAL VIDEO FIBER OPTIC TRANSPORT and DISTRIBUTION SYSTEM FOR HDTV and SDTV 191 FOREST AVENUE LOCUST VALLEY, NY 11560-2132 USA (800)-488-8378 / (516)-671-7278 FAX (516)-671-3362 sales@multidyne.com www.multidyne.com REV C, Feb 24, 2015...
- Page 2 MULTIDYNE, the Multidyne logo and HD3000-xxx are registered trademarks of MULTIDYNE Electronics, Inc. Copyright 2013 MULTIDYNE Electronics, Inc., Locust Valley, New York. Printed in the United States of America. All Rights Reserved. Contents of this publication may not be reproduced in any form without the written permission of MULTIDYNE Electronics, Inc.
- Page 3 TABLE OF CONTENTS INTRODUCTION ........................1 APPENDIX A. BLOCK DIAGRAMS ..................4 APPENDIX B. TECHNICAL SPECIFICATIONS ..............6 REV C, Feb 24, 2015...
- Page 4 LC, ST, FC or SC connectors, depending on the converter model selected. MultiDyne’s HD-3000-II converters are compliant with all SMPTE specifications and are housed in a rugged enclosure that stands up to daily production, both in the studio and in the field.
- Page 5 Instruction Manual, HD3000 Series The transmitter front panels include SD, HD and 3G Rate LEDs for 270, 1485, or 2970 MBPS, and a STATUS LED for Carrier Detect. The Rate LEDs indicate which of the 3 possible SMPTE rates the reclocker PLL has locked to. In the transmitters, the STATUS LED glows green when a signal is present at the BNC input.
- Page 6 Instruction Manual, HD3000 Series POWER REQUIREMENTS The HD3000 Series operates from 115 or 230 VAC with a wall-mount power supply or 9 to 24 VDC @ >= 1A using a coaxial type connector (sleeve ground) on the rear panel labeled POWER 9~24VDC.
- Page 7 Instruction Manual, HD3000 Series APPENDIX A. Block Diagrams -1TX -2TX -1RX REV C, Feb 24, 2015...
- Page 8 Instruction Manual, HD3000 Series -2RX -TRX REV C, Feb 24, 2015...
- Page 9 Instruction Manual, HD3000 Series APPENDIX B. Technical Specifications Video Bit Rates: 125 to 2970 MBPS # of Ins/outs: 1 or 2 BNC(model dependent) Impedance 75 Ohms Level 800mV (peak to peak) Standard: SMPTE 425M, 297M, 292M, 259M-C & DVB-ASI Bit Error Rate (@-22dBm) Return Loss: >15 dB at 5 MHz - 1.485 GHz, >10 dB at 1.5 GHz to 3 GHz Jitter(wideband)
