INSTALL THE UNIT INTO THE
3
WALL CASE
Slide the unit into the wall case and secure with four
screws through the unit flange holes.
Installation Instructions
REPLACE THE ROOM CABINET
4
Reinstall the room cabinet by hooking the top over
the rail along the unit top (1), then pushing it in at
the bottom (2).
18
