π
H-4406
ALUMINUM
BLEACHERS
3-ROW x 15'
TOOLS NEEDED
Square
End Cap x 10
3/8" Bolt x 8
5/16" Carriage Bolt x 30
WARNING! DO NOT ALLOW THESE
ALUMINUM BLEACHER COMPONENTS
TO GET WET! COMPONENTS THAT
ARE BUNDLED AND GET WET WILL
DISCOLOR!
NOTE: If components are to be stored
where they may be subjected to moisture,
break bundles and separate or restack
leg-to-leg so that components have
no flat surfaces touching together. This
will prevent chemical reaction which is
unsightly, but purely cosmetic.
NO CLAIMS WILL BE ALLOWED FOR SUCH
ALUMINUM DISCOLORATION.
CAUTION! All outdoor bleachers must be
anchored to meet wind loads as specified
by applicable building codes.
PAGE 1 OF 4
1-800-295-5510
uline.com
Tape Measure
Rubber Mallet
#8 x 1/2" Self-Tapping
Stainless Screw x 20
3/8" Flange Nut x 8
5/16" Flange Nut x 30
Socket Wrench
Electric Drill
with #2 Phillips Bit
PARTS
Clip x 30
Frame x 3
15' x 10" x 2" Anodized Seat Plank x 3
15' x 10" x 2" Mill Foot Plank x 2
X-Brace with End Notches x 2
X-Brace without End Notches x 2
1/2" Deep Well
Socket
9/16" Deep Well
Socket
9/16" Wrench
0214 IH-4406
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for U-Line H-4406
Summary of Contents for U-Line H-4406
- Page 1 π H-4406 1-800-295-5510 uline.com ALUMINUM BLEACHERS 3-ROW x 15' TOOLS NEEDED 1/2" Deep Well Socket Tape Measure Socket Wrench 9/16" Deep Well Socket Electric Drill Square Rubber Mallet with #2 Phillips Bit 9/16" Wrench PARTS End Cap x 10 #8 x 1/2" Self-Tapping...
- Page 2 ASSEMBLY INSTRUCTIONS 1. Attach end caps to seat planks and foot planks. 3. Position frames in place, standing up, 6 feet apart. Make sure the pre-drilled holes on the end caps (See Figure 4) are on the underside of the planks. Use a rubber mallet to tap into place.
- Page 3 ASSEMBLY INSTRUCTIONS CONTINUED 5. At this point frame is able to stand up on its own. Figure 7 Figure 8 Make sure the frame is straight, square and level. Tighten all 3/8" bolt connections with socket wrench. (See Figure 10) Figure 10 Using other end of assembled X-brace from the right frame, attach to the bottom hole and third...
- Page 4 ASSEMBLY INSTRUCTIONS CONTINUED 7. Attach foot planks. Beginning with the bottom row, Figure 17 place one foot plank on top of the clips, making 5/16" Carriage Bolt sure the clips rest under the plank in the outside Hold Down Clip channels.
