Related Manuals for Coway BA35-A
Summary of Contents for Coway BA35-A
- Page 1 Coway Battery-Powered Bidet BA35-A • For your safety and proper use of the product, please read this user manual before use.
- Page 2 Easy Battery Replacement · With Coway’s easy rotating structure applied to the back of the bidet’s control panel, anyone can easily replace the batteries. (Requires 3 AA batteries) Strong and Gentle Hybrid Water Flow ·...
-
Page 3: Table Of Contents
DEAR CUSTOMERS Coway Battery-Powered Bidet. Thank you for using our Please read this user manual to use and maintain the product correctly. If you encounter a problem while using the product, Please refer to the user manual to solve the problem. -
Page 4: Safety Information
SAFETY INFORMATION Make sure to follow these instructions for your safety! These instructions are intended to keep the users safe and prevent property damage. Please use the product correctly after reading the precautions carefully. DANGER : Death or serious injury may occur if the instruction is not followed. -
Page 5: During Use
This product is only intended for use in the bathroom and should be used in accordance with Tips the user manual. Do not use for any other purposes. During Use Do not bring the product close to an electric heater or throw fire objects such as a burning cigarette into the toilet. - Page 6 SAFETY INFORMATION DANGER : Death or serious injury may occur if the instruction is not followed. WARNING : Severe bodily injury or property damage may occur if the instruction is not followed. CAUTION : Minor bodily injury or property damage may occur if the instruction is not followed.
-
Page 7: Others
It may damage or break the product. ∗ If foreign materials enter the product, close the main water valve, and call the Coway service center. Do not disassemble, repair, or modify the product on your own. It may damage or break the product. -
Page 8: Part Names
PART NAMES Front/Rear view Seat cover Caution sticker Front/Rear nozzle Bidet Water tank hose Seat caution sticker Bidet hose Seat Water pipe Display panel T-shaped connector /Control panel Valve for main water supply Product sticker Cover screw 3 Batteries (AA) - Page 9 Installation kit Anchor screws X 2 Installation plate X 1 Anchor rubbers X 2 Anchor washers X 2 Batteries (AA) X 3 Anchor nuts X 2 T-shaped connector X 1 Bidet hose X 1 Rubber packing X 1 Cover screw X 1 Fixing sliders X 2 ∗...
- Page 10 BUTTONS AND DISPLAY PANEL Display panel Control panel Display panel/Control panel BA35-A Low battery indicator Stop button Water pressure button Water pressure indicator Rear button Nozzle position button Front button...
- Page 11 Display panel Low battery indicator When the battery needs to be replaced, the LED flashes. Water pressure indicator Press the water pressure button to adjust the pressure between level 1 and 2. Control Panel Stop button Rear button All operating functions Use this button to use the rear will stop.
- Page 12 USING YOUR BIDET Seat on the seat - Functions become available when the seat sensor is activated. - You must sit on the seat for at least 3seconds in order to activate the bidet. - The sensor in the seat may not work properly depending on the way in which the user sits on the seat.
- Page 13 CHOOSING THE DESIRED CLEANSING For rear cleansing ■ Cleansing When seated, press the ‘Rear’ button. - Cleansing water will spray for approximately 1 minute and then automatically stopped. - Self-cleaning is performed for approximately 6 seconds after the nozzle retracts itself. ∗...
- Page 14 CHOOSING THE DESIRED CLEANSING For front cleansing ■ Cleansing When seated, press the ‘Front’ button. - Cleansing water will spray for approximately 1 minute and then automatically stopped. - Self-cleaning is performed for approximately 6 seconds after the nozzle retracts itself. ∗...
-
Page 15: Installation
Store the existing product away from direct sunlight. ■ Cold water pipe Make sure to connect the bidet to a cold water pipe. Consult with a Coway technician for the detailed installation method to ensure optimal performance of the product. Tips... -
Page 16: Remove Existing Toilet Seat
INSTALLATION Remove existing toilet seat Remove the anchor nuts to detach the existing toilet seat ① and the cover ②. ∗ Store the removed seat and seat cover safely in a place with no direct sunlight. Install product 1. Close the main water supply valve ① then remove the existing water tank hose ②. - Page 17 8. Insert 3 new AA batteries into the battery cartridge. (see page 19) 9. Check if the main unit is ready to operate normally. - If the Red LED indicator on the control panel blinks, contact your COWAY service center.
- Page 18 CLEANING Cleaning the product body Use a soft cloth or sponge with a neutral detergent to clean the bidet. Failure to do so may result in product deformation or damage. The product body and the controller should never be cleaned with water. Do not use a neutral detergent or kitchen detergent that contains thinner, benzene, hydrochloric acid detergent, or abrasives.
- Page 19 MAINTENANCE Removing the product 1. Close the main water supply valve. 2. Pull the product forwards by holding both sides of the product while pressing the button at the bottom right of the product, to separate the product from the installation plate. Replacing the mesh filter When the water pressure gets low or the product has been used for a long time, replace the old mesh filter into a new one.
- Page 20 MAINTENANCE Replacing the batteries 1. After removing the cover, remove 2 screws to open the battery lid. 2. Rotate the battery cartridge assembly 90 degrees. 3. Remove 3 AA batteries in the battery cartridge and insert 3 new AA batteries. - Check +, - poles when replacing the batteries.
- Page 21 4. Rotate the battery cartridge cap on the control panel to close it. After rotating the cartridge cap, assemble it by rotating to the fully tightened position. ∗ After replacing the battery, make sure the main body and the cartridge cap are fully engaged. 5.
- Page 22 TROUBLESHOOTING The bidet may operate abnormally due to minor causes not because of a product malfunction but because the user is unfamiliar with using the product. In such a case, problems can be easily solved even without the help of the Service Center by checking the following. If you cannot solve the problem after checking the following items, please call the Service Center.
- Page 23 Symptom Check Solution • Do the batteries need replacing? Replace the batteries. The control panel • Are the batteries inserted the in the correct Reinsert the batteries in the correct does not work. positions. position(+/-)? • Is the toilet seat sensor working properly? Refer to the seat sensor instructions.
- Page 24 0 ℃ ~ 40 ℃ Operating temperature The specifications are subject to change for the purpose of improving product performance. MALAYSIA Add: Coway (Malaysia) Sdn. Bhd. Level 20, Ilham Tower, No. 8, Jalan Binjai, 50450 Kuala Lumpur. Call center : 1-800-888-111...
- Page 25 MEMO...
- Page 26 MEMO...
- Page 27 MEMO...
- Page 28 MADE IN KOREA 1231843 www.coway.com...
