BAS25-AMY
Coway Self-Sterilising Bidet
· This product is designed for use in Korea. This product can not be used if the voltage is different from that mentioned in the
rating plate.
· Please read this User Manual before using this product for your safety and proper usage of it.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAS25-AMY and is the answer not in the manual?

Questions and answers

Related Manuals for Coway BAS25-AMY

Summary of Contents for Coway BAS25-AMY

  • Page 1 BAS25-AMY Coway Self-Sterilising Bidet · This product is designed for use in Korea. This product can not be used if the voltage is different from that mentioned in the rating plate. · Please read this User Manual before using this product for your safety and proper usage of it.
  • Page 2 (RF) remote control which can be used in any direction. Super power saving, GREENPLUG system · This super power saving technology developed by Coway, can remember and adjust according to the most used and least used time of the day. This allows the bidet’s...

  • Page 3: Table Of Contents

    DEAR CUSTOMERS Coway Self-Sterilising Bidet. Thank you for using the Please read this User Manual to use and maintain the product correctly. If you encounter any problem while using the product, please refer to the User Manual to solve the problem.

  • Page 4: Safety Precautions

    Unplug the product if the product will not be in use for a prolonged period. Failure to do so may result in electric shock or fire. If the power cord is damaged, do not replace the cord by yourself. Contact the Coway Service Center to have it replaced.

  • Page 5: Installation

    Operation If the product produces strange noise, burnt smell or emits smoke, unplug immediately from the electrical outlet and contact the Coway service center. Failure to do so may result in electric shock or fire. Do not place an electrical heater near the product or dispose any burning materials such as a lit cigarette in the toilet.
  • Page 6 * Unplug the product immediately, close the valve for the main water supply, and contact the Coway service center. Failure to do so may result in electric shock or fire. Close the valve for the main water supply when replacing the filter.

  • Page 7: Other

    If there is a problem with the remote control, use the side buttons on the bidet for operation. Contact the Coway service center for examination if the problem persists. * Do not carry or store the remote control with other communication devices, such as a walkie-talkie or a mobile phone.

  • Page 8: Part Names

    PART NAMES Front/Rear View Seat cover 1 Caution sticker 1 Rear nozzle 1 Body sensor sticker 1 Bidet 1 Front nozzle 1 Water tank hose 1 Bidet hose 1 Seat 1 Water pipe 1 T-shaped connector 1 Valve for main water supply 1 Power cord 1 Product sticker...

  • Page 9: Installation Kit

    Installation kit 2 Anchor screws 1 Bidet hose 2 Anchor rubbers 2 Anchor washers 2 Anchor nuts 1 Filter clip 1 Installation adapter 1 MF 1 Filter fixing stopper 1 Installation plate 2 Fixing sliders 1 Silicone sealant 3 AAA batteries * Parts mentioned above may vary depending on the manufacturer.
  • Page 10 IMPORTANT!  Connect product to power. Plug the power cord and press the Power button on the control panel to turn on the bidet. The bidet only functions properly when it is connected to power. This product is for 220 ~ 240 V - 50 Hz only. Connect the power plug to a grounded electrical outlet for 220 ~ 240 V - 50 Hz.
  • Page 11 How to connect with the remote control (pairing)  How to pair the remote control with the product Pairing is creating a wireless connection between the controller of the remote control and the bidet. Follow the instructions below to correctly pair the remote control with the bidet. 1.
  • Page 12 IMPORTANT! How to set special modes Press and hold the Power button together with the Cleansing button on the control panel for 2 seconds. There will be a "beep" sound and the LED will turn off, indicating that the mode is being accessed. You will be automatically directed out of the special mode if no action is taken for 10 seconds.
  • Page 13 BUTTONS AND DISPLAY PANEL Product body Nozzle Cleaning button Rear cleansing button Power button RF remote control Display panel Control panel Stop button WIDE function indicator Rear cleansing button Water pressure adjustment/ Front cleansing button Nozzle position indicator Cleansing water / Dryer button dryer temperature WIDE Adjustment button...
  • Page 14 BUTTONS AND DISPLAY PANEL Display panel WIDE function indicator Water pressure indicator/ Nozzle position indicator When the WIDE button is pressed, the LED changes to following the Press the Water Pressure button to levels: adjust the pressure from level 1 to 5. 1 (Green) →...
  • Page 15 Water Pressure Adjustment button Nozzle Adjustment button Water pressure can be adjusted in 5 levels. The Press the button to move the nozzle back or forth selected water pressure indicator will light up while cleansing/bidet cleansing function is in each time when the button is being pressed. operation.
  • Page 16 AUTOMATIC STERILISATION/REAR CLEANSING WITH STERILE WATER Automatic sterilisation system  What is an automatic sterilisation function Good hygiene is achieved with the 2-step sterilisation of the hose → and nozzle, which ensures hygiene both inside and outside of the bidet. This 2-step total automated system for sterilisation is operated once a day (based on 12 bidet uses a day).
  • Page 17 CHOOSING THE DESIRED CLEANSING For rear cleansing  Cleansing Sit down and press the Cleansing button on the control panel. - The nozzle drains cold water before cleansing water is sprayed so cleansing begins at the previously set temperature. - Cleansing water will spray for 1 minute and stop automatically. - When the nozzle retracts, the nozzle is cleaned automatically for 6 seconds.
  • Page 18 CHOOSING THE DESIRED CLEANSING For front cleansing  Front cleansing Sit down on the bidet and press the Front Cleansing button on the remote control. - The front nozzle drains cold water in the nozzle, before water is sprayed so cleansing can be done at a warm temperature.
  • Page 19 For child function (cleansing)  Child function Sit down and press the Child button on the remote control. There will be a beep sound and the child function will be activated. - You can adjust the water pressure, water temperature, warm air and nozzle position according to the child's preference.

  • Page 20: Installation

    Remove and replace the old batteries (3 X 1.5 V AAA). Reattach the cover and tighten the screws clockwise. * Take caution not to lose the screws. Consult with a Coway technician for the detailed installation method to ensure optimal Tips performance of the product.

  • Page 21: Removing Existing Toilet Seat

    Remove existing toilet seat Remove the anchor nuts to detach the existing toilet seat (①) and the cover (②). * Store the removed toilet seat and cover away from direct sunlight. Install product 1. Close the main water supply valve (①) then remove the existing water tank hose (②).
  • Page 22 INSTALLATION 4. Place the fixing slider over the installation plate on the toilet, insert the fixing bolts, and fasten the nuts so that the installation plate is fixed. 5. Match the back of the product to the installation plate, by pressing the button down.
  • Page 23 Install the remote control 1. Clean the surface with a dry cloth and install the remote control. * Moisture may weaken the adhesion. 2. Apply sealant in 8 grooves at the back of the adjustable bracket. The sealant should be 2mm thick. * Take caution as too much sealant may get on the double-sided tape and weaken its adhesion.
  • Page 24 INSTALLATION Precautions for placing the remote control  Example of correct usage Precautions for placing the remote control to prevent it dropping: Place the remote control in the holder from front. * Place the remote control in the holder from the front side- as shown in the image. ...
  • Page 25 CLEANING Clean the nozzle 1. Press and hold the Power button for 2 seconds to turn off the bidet. 2. Press the Nozzle Cleaning button on the control panel. - The cleansing nozzle protrudes and cleansing water is sprayed on it. - The cleansing nozzle is being cleaned.
  • Page 26 CLEANING Clean the product body  Use a soft cloth or sponge with a neutral detergent to clean the bidet. - Failure to do so may result in product deformation or damage. Disconnect the power plug from the electrical outlet when removing and cleaning the nozzle/drying duct.
  • Page 27 Removing the product 1. Disconnect the power plug from the electrical outlet. 2. Lock the main water supply valve. 3. Press and hold the button at bottom right part of the product and separate the product by holding both sides and pulling it from the installation plate.
  • Page 28 MAINTENANCE Regularly examine the product to guarantee safe usage. Check the following items regularly to maintain the bidet at its best condition. Maintenance  Power - When the power cord is being moved when connected, does the display panel blink as it is turned on and off? - Is there any part of the electric power cord which is hotter than usual? - Is there any part of the electric power cord which is deformed, discolored or damaged?
  • Page 29 FILTER REPLACEMENT Replace the filter! 1. Unplug the power plug and close the main water supply valve. 2. Turn the MF to remove it from the filter fixing stopper in the direction as shown in the image. 3. Insert the new MF in filter fixing stopper in the direction as shown in the image until it is firmly in place.
  • Page 30 Put new batteries in the remote control. Put new batteries in the remote control. Contact the Coway service center if the • Is the remote control turned off? problem persists after the batteries are replaced.
  • Page 31 Problem Check Possible Solutions • Water flowing out, from the nozzle after cleaning, is a self-cleansing method and not a sign of a Water comes out even malfunction. after the bidet is being • Sometimes water droplets around the nozzle may drop into the toilet. stopped.
  • Page 32 Product Specifications Product Name Coway Electronic Bidet BAS25-AMY Model BAS25-AMY 240 V - 50 ㎐ Rated voltage Power consumption 1,060 W Power cord 1.8 m Water pressure 0.1 MPa - 0.68 MPa Dimensions 412 mm (W) × 534 mm (D) × 161 mm (H) Weight 4.5 Kg...
  • Page 33 MEMO...
  • Page 34 MEMO...
  • Page 35 MEMO...
  • Page 36 1228375 www.coway.com...
