- Page 1 OWNERS MANUAL Model No. 45-03732 SUN SHADE • Safety CAUTION: • Assembly Read Rules for • Operation Safe Operation • Maintenance and Instructions • Parts Carefully the fastest way to purchase parts www.speedepart.com PRINTED IN USA FORM NO. 40921 (08/17/2017)
- Page 2 SAFETY RULES 4. The sun shade will restrict your field of vision in some directions. Use extra caution when operating your tractor with the sun shade attached. Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the 5.
- Page 3 HARDWARE PACKAGE SHOWN FULL SIZE NOT SHOWN FULL SIZE REF. QTY. DESCRIPTION REF. QTY. DESCRIPTION Carriage Bolt, 5/16" x 2" Flat Washer, 5/16" Hex Bolt, 1/4" x 1-1/2" Adhesive Pad Hex Bolt, 5/16" x 1" Plastic Knob Hex Bolt, 1/4" x 3/4" Plastic Cap Nylock Nut, 1/4"...
- Page 4 TOOLS REQUIRED FOR ASSEMBLY STEP 2: (SEE FIGURE 2) • Raise the tractor seat and remove the seat springs and four bolts from the rear fender using a 1/2" socket. 7/16" Wrenches • Place the support brackets against the rear of the 1/2"...
- Page 5 FOR GARDEN TRACTORS ONLY FOR ALL TRACTORS STEP 4: STEP 3: (SEE FIGURE 4) (SEE FIGURE 3) • Assemble the upright tubes to the holes in the base • Raise the tractor seat and remove the seat springs assembly using a 5/16-18 x 2" carriage bolt (A), 5/16" and four bolts from the rear fender using a 1/2"...
- Page 6 OPERATION STEP 5: (SEE FIGURE 5) • Assemble the top tubes to the upright tubes using two 1/4" x 1-1/2" hex bolts (B) (outside) and two 1/4" Read this owner's manual and safety rules before nylock nuts (E) (inside). Do not tighten yet. operating your tractor with the sun shade.
- Page 7 REPAIR PARTS FOR MODEL 45-03732 SUN SHADE REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION 66296 Base Bracket Assembly 43648 Hex Bolt, 1/4-20 x 1-1/2" 25014 Upright Tube 47189 Nylock Nut, 1/4-20 25013 Top Tube 43012 Hex Bolt, 1/4-20 x 3/4"...
- Page 8 REPAIR PARTS Agri-Fab, Inc. 809 South Hamilton Sullivan, IL. 61951 217-728-8388 © 2017 Agri-Fab, Inc. www.agri-fab.com...
