Summary of Contents for AVIRON Impact Series

  • Page 1 Impact Series Rower Service Manual...
  • Page 2 CONTENTS Parts Reference step Shroud 1→2 Tension cable 1→2→4 Motor 1→2→4→9 Sensor 1→2→7 Magnetic wheel w/fan 1→2→4→5 Belt 1→2→4→5→6 Return spring assembly 1→2→3→5.1→6.1→7→8 Slider assembly (w/ PU wheel) 11→12 Cable 1→2→10...
  • Page 3 INSTRUCTIONS Step 1 Remove shroud-1...
  • Page 4 INSTRUCTIONS Step 2 Remove shroud-2...
  • Page 5 INSTRUCTIONS Step 3 Remove handlebar...
  • Page 6 INSTRUCTIONS Step 4 Remove tension cable Before removing the tension cable, adjust the resistence to the heaviest level.
  • Page 7 INSTRUCTIONS Step 5.1 Step 5.2...
  • Page 8 INSTRUCTIONS Step 6.1 Remove belt Step 6.2...
  • Page 9 INSTRUCTIONS Step 7 Remove sensor Step 8 Remove return spring assembly...
  • Page 10 INSTRUCTIONS Step 9 Remove motor Step 10 Remove cable...
  • Page 11 INSTRUCTIONS Step 11 Remove saddle Step 12 Remove Slider assembly (w/ PU wheel) 106A 106A...
  • Page 12 Aviron Interactive Inc. 780 Birchmount Rd. Unit 16 Toronto, Ontario M1K 5H4, Canada Phone: 437-317-1199 Email: info@avironactive.com www.avironactive.com...
