  • Page 1 Tough Series Rower User Manual...
  • Page 3 Connected. Competitive. Exhilarating. This guide will help you safely setup the equipment and get you started. You can find additional help and tutorials in the Aviron application help menu or our website www.avironactive.com We are excited to get you started!
  • Page 4 CAMERA AND MICROPHONE SLEEP BUTTON VOLUME CONTROL HEADPHONE JACK INCREASE RESISTANCE DECREASE RESISTANCE BACK BUTTON ETHERNET PORT LOCATED AT REAR CAUTION: Any changes or modifications to this equipment could void the equipment warranty. Any service other than cleaning or user maintenance must be performed by an authorized service representative.

  • Page 5: Workout Screen

    WORKOUT SCREEN leaderBoard split time Your position highlighted in red in Projected minutes to travel 500 meters relation to other players resistance leVel players time remaining/elapsed See other players and their position Watts checKpoint Watts per stroke meters traVeled TOTal OUTPUT (KJ) exit stroKe rate Strokes per minute...

  • Page 6: Specifications

    SPECIFICATIONS ROWER FRAME High strength aluminum RESISTANCE 16 level dual air & magnetic system BELT Industrial poly-v belt SEAT Ergonomic seat with extra rear support DIMENSIONS 249.5 x 53 x 111 cm WEIGHT 125LBS / 56.5KG MAX USER WEIGHT 507LBS / 230KG...

  • Page 7: Touch Screen

    SPECIFICATIONS TOUCHSCREEN SCREEN 21.5” 1080P touchscreen PROCESSORS ARM 2.0Ghz dual core & 1.5Ghz quad core GRAPHICS ARM Mali-T864 GPU MEMORY 4GB RAM STORAGE 32GB eMMC flash Android 7.0 WIFI 802.11 b/g/n/ac ETHERNET 10/100Mbps BLUETOOTH CAMERA 2 megapixel front-facing SPEAKERS 2x2 watt stereo CERTIFICATIONS FCC &...

  • Page 8: Safety Instructions

    Safety Instructions Read all instructions before assembling and using the equipment. These instructions are for your safety and to protect the equipment. Periodically consult your physician before using the equipment. If at any time you feel faint, dizzy or are experiencing pain, stop and consult your physician immediately.
  • Page 9 Warm-up Stretch for 5 to 10 minutes prior to exercising. Warm-up for 5 to 10 minutes prior to exercising. The warm-up should gently prepare the body for exercises by gradually increasing the heart rate and circulation; this will loosen the joints and increase blood flow to the muscles.
  • Page 10 ASSEMBLY INSTRUCTIONS Step 1 Step 2...
  • Page 11 ASSEMBLY INSTRUCTIONS Step 3 Step 4...
  • Page 12 ASSEMBLY INSTRUCTIONS Step 5...
  • Page 13 ASSEMBLY INSTRUCTIONS Step 6...
  • Page 14 ASSEMBLY INSTRUCTIONS Step 7 Step 8...

  • Page 15: Pedal Adjustment

    ASSEMBLY INSTRUCTIONS Step 9 PEDAL ADJUSTMENT...
  • Page 16 ASSEMBLY INSTRUCTIONS Step 10...
  • Page 17 ASSEMBLY INSTRUCTIONS Step 11 ATTENTION: Washers go in between the bracket arm and the bracket, not on the outside of the bracket.
  • Page 18 ASSEMBLY INSTRUCTIONS...

  • Page 19: Part List

    PART LIST DESCRIPTION MAIN FRAME CENTRAL BEAM FRONT STABILIZER REAR STABILIZER HAND GRIP HOLDER HANDLE PEDAL BASE PEDAL SUPPORT TUBE SLIDING SUPPORT SIDE PLATE REAR STABILIZER HOLDING BRACKET SLIDING SUPPORT BAFFLE PLATE TOUCHSCREEN WASHER SADDLE FOOT CAP TRANSPORTATION WHEEL FOOT PAD END CAP FOR CENTRAL BEAM PEDAL (A) PEDAL ADJUSTMENT BOTTOM...
  • Page 20 PART LIST DESCRIPTION PEDAL ADJUSTMENT BOTTOM HOLDER PEDAL NUT (R) PEDAL BOLT PEDAL NUT (L) ROLLER (A) BEARING 608ZZ POWDER METAL SPACER (12 X 8 X 2MM) ROUND HEAD BOLT M8 X 25MM PAN HEAD BOLT M8 X 25MM ROLLER (B) POWDER METAL SPACER (12 X 8 X 5MM) SOCKET HEAD SCREW M6 X 10MM WIRE UPPER...

  • Page 21: Connecting To A Network

    CONNECTING TO A NETWORK After assembling the rower, to connect to a network using an ethernet cable, simply plug in the ethernet cable into the ethernet port located at the rear of the touchscreen. To connect to a network using Wi-Fi, follow the instructions below: 1.
  • Page 22 CONNECTING TO A NETWORK 2. after the touchscreen finishes loading, select the user icon located at the top left of the screen. 3. select “aViron login”. AVIRON LOGIN 4. Enter “admin” as the Email address (case sensitive). 5. Enter the machine ID as the password (case sensitive).
  • Page 23 CONNECTING TO A NETWORK 8. select “system settings” SYSTEM SETTINGS 9. select “Wi-Fi” 10. Enable Wi-Fi by switching the icon to the ON position. 11. select your preferred Wi-Fi network and enter in the password.
  • Page 24 To access admin settings, follow the instructions below: 1. Select the user icon located at the top left of the screen. 2. select “aViron login” 3. Enter “admin” as the Email address (case sensitive). 4. Enter the machine ID as the password (case sensitive).

  • Page 25: General Maintenance

    (including negligence), misrepresentation, strict liability, breach of contract or breach of warranty of Aviron or any supplier, and even if Aviron has been advised of the possibility of such damages. In no event shall Aviron’s liability hereunder, if any, exceed the purchase price paid by the customer...

  • Page 26: Limited Warranty

    Terms and Conditions 1. The warranty applies to the Aviron equipment only while it remains in the possession of the original customer or company who has registered the equipment.
  • Page 27 Aviron but all claims for warranty service must be made within the warranty period. No repair or replacement of any equipment or part thereof shall extend the warranty period as to the entire equipment.

  • Page 28: Contact Information

    Contact Information aviron Interactive Inc. www.avironactive.com 780 Birchmount Rd. Unit 16 Toronto, Ontario M1K 5H4, Canada Phone: 437-317-1199 General Email: info@avironactive.com Support Email: support@avironactive.com...
  • Page 29 FCC Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
